HARDWARE SETTING
Parameter Allowable range Description
ENCODER PULSES 2
(T, TM, P, CO)
32 ÷ 1024 This parameter defines the number of encoder pulses per
revolution. It must be set equal to ENCODER PULSES 1;
otherwise the controller raises an alarm.
The available options are:
32, 48, 64, 80, 64, 128, 256, 512, 1024
NOTE: with standard HW the capability to use
encoders with high number of pulses could be
limited depending on the speed. Ask to Zapi
technicians before changing this parameter.
MOTOR P. PAIRS 1
(T, TM, P, CO)
1 ÷ 30 This parameter defines the number of pole pairs of the
traction motor. It must be set equal to MOTOR P. PAIRS 2;
otherwise the controller raises an alarm.
MOTOR P. PAIRS 2
(T, TM, P, CO)
1 ÷ 30 This parameter defines the number of pole pairs of the
traction motor. It must be set equal to MOTOR P. PAIRS 1;
otherwise the controller raises an alarm.
7.2.6 HYDRO SETTING
HYDRO SETTING
Parameter Allowable range Description
HYDRO TIME
(A)
0 s ÷ 200 s
(steps of 1 s)
This parameter defines the delay time between the
release of the hydraulic-function request and the actual
stop/release of the associated output, according to the
HYDRO FUNCTION setting and the HW configuration.
HYDRO FUNCTION
(A)
NONE ÷ OPTION #2 This parameter defines how the pump feeding hydraulics is
managed.
NONE = no hydraulic functions are present;
KEYON = ACE3 constantly drives the pump motor
from key-on.
RUNNING = ACE3 drives the pump motor only upon
an associated request (for example a lift request).
OPTION #1 = ACE3 does not drive the pump motor,
but the truck integrates hydraulics and ACE3 acts as
master controller managing a valve. The output that
drives the hydraulic valve (for example EVP) is
activated at key-on.
OPTION #2 = like OPTION#1, except the valve is
driven only upon request.
