Zapi ACE3 User Manual

AFFZP0BB – ACE3 – User Manual Page – 103/139
9.2 Alarms – Supervisor uC
Error
Code
Effect
Machine
status
When the
test is
done
Restart
procedure
Indication
CAN
OPEN
CODE
MDI
CODE
ZAPI
CODE
LED
BLINKS
WATCHDOG
MC is opened,
EB is applied,
traction/pump stopped
Stand-by,
running
Key re-cycle 0X6010 8 8 8
CONTROLLER
MISM.
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up
Install the correct
software and Key
re-cycle
0XFFEF 12 239 12
SP MISMATCH xx
MC is opened,
EB is applied,
traction/pump stopped
Running Key re-cycle 0XFFF2 15 242 15
OUT MISMATCH xx
MC is opened,
EB is applied,
traction/pump stopped
Running Key re-cycle 0XFFE3 16 227 16
LOGIC FAILURE #1
MC is opened,
EB is applied,
traction/pump stopped
Stand-by,
running
Valves or
Traction/Pump
Request
0X5114 19 19 19
LOGIC FAILURE #3
MC is opened,
EB is applied,
traction/pump stopped
Stand-by,
running
Valves or
Traction/Pump
Request
0XFF11 17 17 17
INPUT MISMATCH
MC is opened, EB is
applied,
Traction/Pump
stopped
Start-up,
standby,
running
Key
re-cycle
0XFFD5 58 213 58
W.SET. TG-EB
Traction/ Pump motor
is stopped
Start-up,
stand-by,
running
Key re-cycle
0XFFD4 59 212 59
NO CAN MSG.
MC is opened, EB is
applied,
Traction/Pump, valves
stopped
Start-up,
stand-by,
running
Valves or
Traction/Pump
Request
0X8130 67 248 67
WRONG RAM MEM.
05
MC is opened, EB is
applied,
Traction/Pump, valves
stopped
Stand-by
Key re-cycle
0XFFD2 71 210 71
VDC LINK OVERV.
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Stand-by,
running
Valves or
Traction/Pump
Request
0XFFCA 77 202 77
WRONG ENC SET
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up
Key re-cycle
0XFF51 85 201 85
ANALOG INPUT
MC is opened,
EB is applied,
traction/pump stopped
Stand-by,
running
Key re-cycle 0XFFFA 96 237 96
