Page – 74/139 AFFZP0BB – ACE3 – User Manual
8.2 PROGRAM LIFT / LOWER function
This function enables to adjust the minimum and maximum useful signal levels of lift
and lowering request. This function is useful when it is necessary to compensate for
asymmetry of the mechanical elements associated with the potentiometer,
especially relating to the minimum level.
This function looks for and records the minimum and maximum potentiometer wiper
voltage over the full mechanical range of the lever.
The values to be acquired are organized in the ADJUSTEMNT list, they are:
- MIN LIFT DC
- MAX LIFT DC
- MIN LOWER
- MAX LOWER
See paragraphs 12.1.4 or 12.2.7 for acquiring procedure.
8.3 PROGRAM STEER function
This enables the adjustment of the minimum and maximum useful signal levels of
the steering control. This function is useful when it is necessary to compensate for
asymmetry with the mechanical elements associated with the steer.
This function looks for and remembers the minimum, neutral and maximum voltage
over the full mechanical range of the steering. It enables compensation for
dissymmetry of the mechanical system between directions.
The values to be acquired are organized in the ADJUSTEMNT group; they are:
- STEER RIGHT VOLT
- STEER LEFT VOLT
- STEER ZERO VOLT
See paragraphs 12.1.5 or 12.2.8 for acquiring procedure.
