Zapi ACE3 User Manual

Page – 40/139 AFFZP0BB – ACE3 – User Manual
7 INVERTER SETTINGS
7.1 Settings overview
Inverter settings are defined by a wide set of parameters, organized as follows.
PARAMETER
CHANGE
SET OPTIONS ADJUSTMENT
SPECIAL
ADJUST.
HARDWARE
SETTING
ACC. TORQUE DEL.
DEC. TORQUE DEL.
ACCELER. DELAY
RELEASE BRAKING
TILLER BRAKING
INVERS. BRAKING
DECEL. BRAKING
PEDAL BRAKING
SPEED LIMIT BRK.
STEER BRAKING
MAX SPEED FORW
MAX SPEED BACK
MAX SPEED LIFT
1ST PUMP SPEED
2ND PUMP SPEED
3RD PUMP SPEED
4TH PUMP SPEED
5TH PUMP SPEED
HYD PUMP SPEED
CUTBACK SPEED 1
CUTBACK SPEED 2
H&S CUTBACK
CTB. STEER ALARM
CURVE SPEED 1
CURVE CUTBACK
FREQUENCY CREEP
TORQUE CREEP
MAX. CURRENT TRA
MAX. CURRENT BRK
ACC SMOOTH
INV SMOOTH
STOP SMOOTH
BRK SMOOTH
STOP BRK SMOOTH
BACKING SPEED
BACKING TIME
EB. ENGAGE DELAY
AUXILIARY TIME
ROLLING DW SPEED
MIN EVP
MAX EVP
EVP OPEN DELAY
EVP CLOSE DELAY
HYDRO TIME
HM DISPLAY OPT.
HM CUSTOM 1 OPT.
HM CUSTOM 2 OPT.
TILL/SEAT SWITCH
EB ON TILLER BRK
BATTERY CHECK
STOP ON RAMP
PULL IN BRAKING
SOFT LANDING
QUICK INVERSION
PEDAL BRK ANALOG
HARD & SOFT
MAIN POT. TYPE
AUX POT. TYPE
SET MOT.TEMPERAT
STEERING TYPE
M.C. FUNCTION
EBRAKE ON APPL.
AUX OUT FUNCTION
SYNCRO
AUTO PARK BRAKE
AUTO LINE CONT.
ACCEL MODULATION
EVP TYPE
EV1
EV2
EV3
EV4
HIGH DYNAMIC
INVERSION MODE
STEER TABLE
WHEELBASE MM
FIXED AXLE MM
STEERING AXLE MM
REAR POT ON LEFT
DISPLAY TYPE
ABS.SENS.ACQUIRE
SET BATTERY
ADJUST KEY VOLT.
ADJUST BATTERY
SET POSITIVE PEB
SET PBRK. MIN
SET PBRK. MAX
MIN LIFT DC
MAX LIFT DC
MIN LOWER
MAX LOWER
THROTTLE 0 ZONE
THROTTLE X1 MAP
THROTTLE Y1 MAP
THROTTLE X2 MAP
THROTTLE Y2 MAP
THROTTLE X3 MAP
THROTTLE Y3 MAP
BAT. MIN ADJ.
BAT. MAX ADJ.
BDI ADJ STARTUP
BDI RESET
BATT.LOW TRESHLD
BAT.ENERGY SAVER
STEER RIGHT VOLT
STEER LEFT VOLT
STEER ZERO VOLT
MAX ANGLE RIGHT
MAX ANGLE LEFT
STEER DEAD ANGLE
STEER ANGLE 1
STEER ANGLE 2
SPEED FACTOR
SPEED ON MDI
LOAD HM FROM MDI
CHECK UP DONE
CHECK UP TYPE
MC VOLTAGE
MC VOLTAGE RED.
EB VOLTAGE
EB VOLTAGE RED.
PWM EV1
PWM EV2
PWM EV3
PWM EV4
PWM EV5
MAX MOTOR TEMP.
STOP MOTOR TEMP.
A.SENS.MAX SE
A.SENS.MIN SE
A.SENS.MAX CE
A.SENS.MIN CE
MOT.T. T.CUTBACK
VACC SETTING
ADJUSTMENT #01
ADJUSTMENT #02
CURR. SENS. COMP
DIS.CUR.FALLBACK
SET CURRENT
SET TEMPERATURE
HW BATTERY RANGE
DUTY PWM CTRAP
HW EXTENSION
PWM AT LOW FREQ
PWM AT HIGH FREQ
FREQ TO SWITCH
DITHER AMPLITUDE
DITHER FREQUENCY
HIGH ADDRESS
CAN BUS SPEED
EXTENDED FORMAT
DEBUG CANMESSAGE
CONTROLLER TYPE
SAFETY LEVEL
RS232 CONSOLLE
ID CANOPEN OFST
2ND SDO ID OFST
VDC START UP LIM
VDC UP LIMIT
VDC START DW LIM
VDC DW LIMIT
TOP MAX SPEED
CONF.POSITIVE LC
FEEDBACK SENSOR
ROTATION CW ENC
ROTATION CW MOT
ENCODER PULSES 1
ENCODER PULSES 2
MOTOR P. PAIRS 1
MOTOR P. PAIRS 2
***
HYDRO SETTINGS
HYDRO TIME
HYDRO FUNCTION
