Zaxis Isaac HD - Input; Output Connector Pin-Out

35
Input / Output Connector Pin-out
Item
Description
PIN
Input Test
Value
IN 1
START
26
1
IN 2
START (ANTI-TIE ENABLED)
27
2
IN 3
BCD 1 (LSB)
28
4
IN 4
BCD 2
21
8
IN 5
BCD 3
22
10
IN 6
BCD 4
23
20
IN 7
BCD 5
24
40
IN 8
BCD 6
25
80
IN 9
BCD 7 (MSB)
16
100
IN 10
NOT USED
17
200
IN 11
NOT USED
18
400
IN 12
ABORT
19
800
+24VDC
User to Supply +24VDC
20
OUT 1
BUSY
1
OUT 2
GLOBAL PASS
2
OUT 3
GLOBAL FAIL
3
OUT 4
CH 1 FAIL
4
OUT 5
CH 2 FAIL
5
OUT 6
CH 3 FAIL
6
OUT 7
CH 4 FAIL
7
OUT 8
CH 1 PASS
8
GND
User to supply GND
9
OUT 9
CH 2 PASS
10
OUT 10
CH 3 PASS
11
OUT 11
CH 4 PASS
12
OUT 12
NOT USED
13
+24VDC
Common to Pin 20
14
GND
Common to Pin 9
15
Required
To
power
the I/O
module
