Figure 41 - RS485 connections with exchange meter
Follow the meter’s manual to configure it correctly, setting the communication address to 32.
The direction of the arrow on the current sensor represents the
installation direction. Pay attention to the insertion direction
Note
The meter settings can be checked in Appendix B – Meter settings.
