4. Connecting to Azzurro EV charging stations
Up to 8 Azzurro EV charging stations can be connected in cascade. Connect the Connext system to
the first EV charging station according to the instructions given here.
1) Connect the 8-pin cable to the ports indicated as CAN port in the relevant figure using a RJ45
connector. For clarity,
2) Figure 10 the pin-out of the RJ45 connector is shown.
Figure 9 – Communication connection
Figure 10 - RJ45 connector pin-out
