Connext User Manual
Rev. 2.2 10/01/2023
9. Access for maintenance only
The Connext system allows internal access via USB for any extraordinary maintenance. To access,
the following materials and tools are required:
- USB Cable (type C)
- Laptop or notebook
- Configuration software supplied by AZZURRO
Maintenance should only be carried out if explicitly requested by Azzurro technical support.
9.1. Access connection for maintenance only
To access, follow the steps below:
1) Check the connections to the various elements (wallbox, inverter, meter, sensors, etc.).
2) Make sure that the power cables of the Connext system in the 3-pin terminal block are
NOT connected/powered.
• L and N power cables disconnected from the system MUST not be
powered so as to prevent the risk of electric shock.
• Connecting to the Connext system with power cables connected
and powered causes a risk of electric shock to the operator.
• Connecting to the Connext system with power cables connected
and powered may cause damage to the system.
3) Access the internal board by unscrewing the four fastening screws of the plastic front
cover. Take care when moving the front cover so as not to damage or disconnect the
internal connections to the display and antenna.
4) Connect the Type-C USB cable to the connector on the main board.
5) Connect the USB cable to the computer and check that the internal LEDs on the main
board light up.
6) Open the maintenance program.
