Zebra GK888t

Maintenance
Replacing the Printhead
70
P1030829-001 GK888t™ User Guide 12/23/10
3. Use the spring to pry the printhead clip off the right side of the carriage.
.
4. Pull the printhead and bracket forward.
.
5. Use a #2 Phillips driver to remove the screw that holds the ground wire.
