1 - 2 TC56 Touch Computer Integrator Guide for Android Version 6.0.1
Figure 1-1 Lift Access Door
2. Slide the microSD card holder to the Open position.
Figure 1-2 Open microSD Card Holder
3. Lift the microSD card holder.
Figure 1-3 Lift microSD Card Holder
4. Insert the microSD card into the card holder door ensuring that the card slides into the holding tabs on each
side of the door.
