2 - 12 TC56 Touch Computer Integrator Guide for Android Version 6.0.1
Figure 2-9 TC56 Battery Charging
2. Ensure the TC56 is seated properly.
Inserting a TC56 with Rugged Boot into Cradle
Each cradle cup has an insert that must be removed prior to inserting the TC56 with Rugged Boot. Remove the
insert and then insert the TC56 into the cup.
Figure 2-10 Remove Insert from Cup
See the TC56 Touch Computer Integrator Guide for Android Version 6.0.1 for information on
installing the 4-Slot Battery Charger onto the cradle.
