CM150 2-4 GA - INSTALLER MENUS
INSTALLERS MENU 221-01164-01/02 (continued)
FACTORY RECOMMENDED SETTINGS 221-01164-02
* 04 Level 0 and 1 are used for Zenith sets. Level 0 is Private Label.
ITEM RANGE 19/20" 25” 27"
00 F Mode 0-1 0 0 0
01 Pre Px 0-1 1 1 1
02 V Pos 0-24 10 7 7
03 H Pos 0-13 10 10 10
04 Level 0-2 1* 1* 1*
05 Band 0-7 0 0 0
06 AC On 1 0 0 0
07 RF Bpf 0-1 1 1
08 3.58T 0-1 1 1 1
09 RF Brt 0-63 32 32 32
10 Aux Brt 0-63 32 32 32
11 V. Size 0-63 36 36 36
12 V. Phase 0-7 5 2 2
13 H. Phase 0-31 19 19 18
14 Aud Lvl 0-63 46 46 46
15 RF Agc 0-63 31 31 33
16 H Afc 0-1 1 1 1
17 WhComp 0-1 0 0 0
18 60 HzSw 0-3 2 2 2
19 PifVco 0-127 31 31 31
20 R Cut 0-254 0 10 5
21 G Cut 0-254 0 10 5
22 B Cut 0-254 0 10 5
23 G Gain 0-254 90 90 90
24 B Gain 0-254 90 90 90
25 C Type 0-5 2 2 2
26 Scroll 0-1 1 1 1
27 6 Keys 0-1 1 1 1
28 SpkrSw 0-1 0 0 0
29 Surf 0-1 0 0 0
30 Vcurve 0-1 0 0 0
Factory Mode 0 (Blue)
Factory Mode 1 (Black)
To Next Page
