Zenith A27A11D - A25 A22 Bt; A25 A22 Bt4; Ga-3 Models; Lga29 A11 Gm

CM150 4-18 GA - MODEL PARTS
MODEL PARTS
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
LGA29A12DM4
Part# Description
009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS
014-12304-01 CABINET REAR, TV, MOLDED PLASTIC
014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-14323 BALUN ASSEMBLY
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
LGA29A12DM84
Part# Description
009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS
014-12304-01 CABINET REAR, TV, MOLDED PLASTIC
014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A
192-00916 LENS, IR
206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-14323 BALUN ASSEMBLY
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR,
A-18695-02 GND STRAP ASSY , CRT
A-19058-01 CRT AND YOKE, ASSEMBLY
LGA29A11GM
Part# Description
009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS
014-12304-01 CABINET REAR, TV, MOLDED PLASTIC
014-12305-07 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-14323 BALUN ASSEMBLY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
GA-3 MODELS
A25A22BT
Part# Description
009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS
012-10571 METAL STAMPING , BRACKET, CRT MOUNTING
012-10694 METAL STAMPING , BRACKET, CRT SUPPORT
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC
014-12230-03 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00887 LENS, INFRARED
206-03436 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535-01 PAD, BUTTONS
A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA
CHASSIS
A25A22BT4
Part# Description
009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS
012-10571 METAL STAMPING , BRACKET, CRT MOUNTING
012-10694 METAL STAMPING , BRACKET, CRT SUPPORT
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC
014-12230-03 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00887 LENS, INFRARED
206-03436 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535-01 PAD, BUTTONS
A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA
CHASSIS
