Zenith A27A11D - A27 A23 W; A27 A23 W4; A27 A23 W8; A27 A23 W84

CM150 4-23 GA - MODEL PARTS
MODEL PARTS
A27A23W
Part# Description
009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12281-04 CABINET FRONT, TV, MOLDED PLASTIC
014-12282-04 CABINET REAR, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00912 LENS, PRIMARY CONTROLS AND IR
206-03373 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION
194-02663 PAD, BUTTONS
A-18769 KEYBOARD ASSEMBLY, 6 BUTTON
A27A23W4
Part# Description
009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC
014-12282-06 CABINET REAR, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00912 LENS, PRIMARY CONTROLS AND IR
206-03373 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION
194-02663 PAD, BUTTONS
A-18769 KEYBOARD ASSEMBLY, 6 BUTTON
A27A23W8
Part# Description
009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12281-04 CABINET FRONT, TV, MOLDED PLASTIC
014-12282-04 CABINET REAR, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00912 LENS, PRIMARY CONTROLS AND IR
206-03373 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058-01 CRT AND YOKE, ASSEMBLY
046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION
194-02663 PAD, BUTTONS
A-18769 KEYBOARD ASSEMBLY, 6 BUTTON
A27A23W84
Part# Description
009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC
014-12282-06 CABINET REAR, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00912 LENS, PRIMARY CONTROLS AND IR
206-03373 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058-01 CRT AND YOKE, ASSEMBLY
046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION
194-02663 PAD, BUTTONS
A-18769 KEYBOARD ASSEMBLY, 6 BUTTON
A27A74R
Part# Description
009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS
002-04084-13 CABINET BACK, PRESSED WOOD
012-10810-01 MOLDED PLASTIC , PANEL, JACK PACK, GA CHASSIS
014-12326 CABINET MAIN, TV, WOOD
019-00961 CABLE TIE, DOUBLE LOOP
020-04330-30 COIL, DEGAUSSER
030-01455-09 DECORATIVE ITEM, CABINET HARDWARE
049-01334-02 SPEAKER, OVAL, 3X6.500
050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP
050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
057-09055-39 ESCUTCHEON, CRT
080-02456-04 SPRING, COMPRESSION
095-03797-05 DEFLECTION YOKE
A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY
197-00180-01 CUP, CABINET BACK
206-03372 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19122 ESCUTCHEON ASSY
046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR
194-02535 PAD, BUTTONS
A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS
A27A74R8
Part# Description
009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS
002-04084-13 CABINET BACK, PRESSED WOOD
012-10810-01 MOLDED PLASTIC , PANEL, JACK PACK, GA CHASSIS
014-12326 CABINET MAIN, TV, WOOD
020-04330-30 COIL, DEGAUSSER
