Zenith A27A11D - A27 A22 Bt; A27 A22 Bt4; A27 A22 Bt8; A27 A22 Bt84

CM150 4-22 GA - MODEL PARTS
MODEL PARTS
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12143-02 CABINET TRAY, MOLDED PLASTIC
014-12181-09 CABINET REAR, TV, MOLDED PLASTIC
014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03373 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
A27A22BT
Part# Description
009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10568 METAL STAMPING , BRACKET, CRT SUPPORT
012-10569 METAL STAMPING , BRACKET, CRT MOUNTING
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12185-10 CABINET REAR, TV, MOLDED PLASTIC
014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03436 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
A27A22BT4
Part# Description
009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10568 METAL STAMPING , BRACKET, CRT SUPPORT
012-10569 METAL STAMPING , BRACKET, CRT MOUNTING
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12185-10 CABINET REAR, TV, MOLDED PLASTIC
014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03797-05 DEFLECTION YOKE
A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03436 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
A27A22BT8
Part# Description
009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10568 METAL STAMPING , BRACKET, CRT SUPPORT
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
012-10900 METAL STAMPING , BRACKET, CRT MOUNTING
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12185-10 CABINET REAR, TV, MOLDED PLASTIC
014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03436 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058 CRT AND YOKE, ASSEMBLY
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
A27A22BT84
Part# Description
009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS
012-10568 METAL STAMPING , BRACKET, CRT SUPPORT
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
012-10900 METAL STAMPING , BRACKET, CRT MOUNTING
014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC
014-12185-10 CABINET REAR, TV, MOLDED PLASTIC
014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-30 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03436 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058 CRT AND YOKE, ASSEMBLY
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
