Zenith A27A11D - Ga2 25 V Contemporary Console Exploded View

CM150 5-5 GA - EXPLODED VIEWS
GA2 25V CONTEMPORARY CONSOLE EXPLODED VIEW
MBR3447
124-00212-35
6
1
4
3
8
7
2
REF DESCRIPTION A25A76R A25A76R7 A25A76R8
1 ESCUTCHEON A-19127 A-19127 A-19127
2 MAIN CABINET 014-12333 014-12333 014-12333
3 SPEAKER 049-01302-03 (2) 049-01302-03 (2) 049-01302-03 (2)
4 CRT ASSEMBLY A63AGD01X A63AFW36X A63AFW36X
5 DEFLECTION YOKE 095-04456-03 095-04456-05 095-04531
6 REAR CABINET 014-11639-19 014-11639-19 014-11639-19
7 MAIN MODULE 009-01831-01 009-01831-02 009-01831-02
8 REMOTE CONTROL 124-00212-35 124-00212-35 124-00212-35
