Zenith A27A11D - A27 A76 R; A27 A76 R8; Lga26 A23 Wm; Lga26 A23 Wm6

CM150 4-24 GA - MODEL PARTS
MODEL PARTS
030-01455-09 DECORATIVE ITEM, CABINET HARDWARE
049-01334-02 SPEAKER, OVAL, 3X6.500
050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP
050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
057-09055-39 ESCUTCHEON, CRT
080-02456-04 SPRING, COMPRESSION
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY
197-00180-01 CUP, CABINET BACK
206-03372 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058 CRT AND YOKE, ASSEMBLY
A-19122 ESCUTCHEON ASSY
046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR
194-02535 PAD, BUTTONS
A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS
A27A76R
Part# Description
009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS
002-04103-02 CABINET BACK
012-10751 METAL STAMPING , STRIKER PLATE
014-11639-20 CABINET REAR, TV, MOLDED PLASTIC
014-12327 CABINET MAIN, TV, WOOD
020-04330-30 COIL, DEGAUSSER
040-00567 HINGE
049-01302-03 SPEAKER, OVAL, 3X5 INCH
049-01334-02 SPEAKER, OVAL, 3X6.500
050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP
050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
057-09055-39 ESCUTCHEON, CRT
095-03797-05 DEFLECTION YOKE
A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL
110-00687-59 GRILLE CLOTH, RECTANGULAR
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY
192-00892 GLASS DOOR
206-03372 INSTR BOOK, OPERATION GUIDE
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19128 ESCUTCHEON ASSY
046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR
194-02535 PAD, BUTTONS
A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS
A27A76R8
Part# Description
009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS
002-04103-02 CABINET BACK
012-10751 METAL STAMPING , STRIKER PLATE
014-11639-20 CABINET REAR, TV, MOLDED PLASTIC
014-12327 CABINET MAIN, TV, WOOD
020-04330-30 COIL, DEGAUSSER
040-00567 HINGE
049-01334-02 SPEAKER, OVAL, 3X6.500
050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP
050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
057-09055-39 ESCUTCHEON, CRT
110-00687-59 GRILLE CLOTH, RECTANGULAR
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY
192-00892 GLASS DOOR
206-03372 INSTR BOOK, OPERATION GUIDE
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A-19058 CRT AND YOKE, ASSEMBLY
A-19128 ESCUTCHEON ASSY
046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR
194-02535 PAD, BUTTONS
A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS
LGA26A23WM
Part# Description
009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS
012-10571 METAL STAMPING , BRACKET, CRT MOUNTING
012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS
014-12143-02 CABINET TRAY, MOLDED PLASTIC
014-12181-09 CABINET REAR, TV, MOLDED PLASTIC
014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER
LGA26A23WM6
Part# Description
009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS
012-10571 METAL STAMPING , BRACKET, CRT MOUNTING
012-10858-01 MOLDED PLASTIC , PANEL, JACK PACK, GA3 CHASSIS
014-12143-02 CABINET TRAY, MOLDED PLASTIC
014-12181-09 CABINET REAR, TV, MOLDED PLASTIC
014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC
050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP
050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04571 DEFLECTION YOKE
A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447
192-00858-01 LENS, PRIMARY CONTROLS AND IR
206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-14323 BALUN ASSEMBLY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS
194-02535 PAD, BUTTONS
