CM150 2-6 GA - INSTALLER MENUS
18 H Afc: There are two setting 0 and 1. Setting is
usually 1.
19 WhComp: (White Compression) There are two
settings 0 and 1. Setting is 0.
20 60hzSw: (60 Hertz compression) There are two
settings 0 and 1. Setting is 0.
21 PifVco: (PIF Voltage Controlled Oscillator)
Range is 0 - 127.
Items # 22 through #26 are for B&W tracking
22 R Cut: Range is 0- 254.
23 G Cut: Range is 0 - 254.
24 B Cut: Range is 0 - 254.
25 G Gain: (Green Gain) Range is 0 - 254.
26 B Gain: (Blue Gain) Range is 0 - 254.
27 Scroll: Selects the method the User Menus that will
appear on the screen. Scroll Off is 1, 1 is On.
28 6 Keys: Set to 1 for the 6 button keyboard.
29 A Att: (Audio Attenuator) Range is 0 - 15.
30 A VCO: (Audio Voltage Controlled Oscillator)
Range is 0 - 63.
31 A Fltr: (Audio Filter) Range is 0 - 63.
32 Spctrl: High Frequency separation. Range is
0 - 63.
INSTALLERS MENU 221-01305-01 (continued)
33 W Band: (Wide Band Low Frequency Separation)
Range is 0 - 63.
34 PiP Z1: Adjusts horizontal position of the insert
picture on left side.
35 PiP Y1: Adjusts vertical position of the insert
picture on left side.
36 PiP X2: Adjusts horizontal position of the insert on
right side.
37 PiP Y2: Adjust vertical position of the insert
picture on right side.
38 PiP Ras: (Picture in Picture Raster) Range is 0
- 255.
39 PiP Sw: (Pip Switch Delay) Used to center PIP
Boarder and PIP picture in the horizontal direction.
Range is 0 - 15.
40 PiPLud: (PIP Luminance Delay) Used to match
Luma and Chroma of inset picture. Range is 0 - 7.
41 PIP Tof: (PIP Tint level register) Range is 0 - 63.
42 C. In OSDC: On screen dispalay internal oscillator.
Range is 0 - 1.
43 OSD FR: On screen display frame. Range is 0 - 1.
