Zenith A27A11D - Page 39

CM150 4-7 GA - MODEL PARTS
MODEL PARTS
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-11 GND STRAP ASSY , CRT
LGA20A05DM8
Part# Description
009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1
CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO
CTV
014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V
MONAURAL, STEREO
020-04330-32 COIL, DEGAUSSER
024-03346 COVER, UNUSED SPEAKER OPENINGS
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER, POSITIONER
192-00917 LENS, IR
206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,
GA,MONO,SC,SPAN
206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,
SPANISH
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18671 CRT AND YOKE, ASSEMBLY
A-18695-11 GND STRAP ASSY , CRT
LGA20A05DM84
Part# Description
009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1
CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO
CTV
014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V
MONAURAL, STEREO
020-04330-32 COIL, DEGAUSSER
024-03346 COVER, UNUSED SPEAKER OPENINGS
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER, POSITIONER
192-00917 LENS, IR
206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,
GA,MONO,SC,SPAN
206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,
SPANISH
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18671 CRT AND YOKE, ASSEMBLY
A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-11 GND STRAP ASSY , CRT
LGA20A11DM
Part# Description
009-01870-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO
CTV
014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V
MONAURAL, STEREO
020-04330-32 COIL, DEGAUSSER
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-03705-12 DEFLECTION YOKE
A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00338 WEDGE, YOKE SPACER
192-00917 LENS, IR
206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-14323 BALUN ASSEMBLY
A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-11 GND STRAP ASSY , CRT
LGA20A11DM7
Part# Description
009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO
CTV
014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V
MONAURAL, STEREO
020-04330-32 COIL, DEGAUSSER
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04557 DEFLECTION YOKE 19V HIBI
A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER, POSITIONER
192-00917 LENS, IR
206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-11 GND STRAP ASSY , CRT
LGA20A11DM74
Part# Description
009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO
CTV
014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V
MONAURAL, STEREO
020-04330-32 COIL, DEGAUSSER
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
095-04557 DEFLECTION YOKE 19V HIBI
A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
