Zenith A27A11D - Page 41

CM150 4-9 GA - MODEL PARTS
MODEL PARTS
GA-2 MODELS
A25A02D
Part# Description
009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS
014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-02 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01989 CONNECTOR AND, CABLE ASSEMBLY
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03369 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
A25A02D4
Part# Description
009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS
014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-06 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01989 CONNECTOR AND, CABLE ASSEMBLY
095-04456-03 DEFLECTION YOKE
A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03369 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
A25A02D64
Part# Description
009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS
014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-06 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01989 CONNECTOR AND, CABLE ASSEMBLY
095-04456-03 DEFLECTION YOKE
A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03369 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-10 GND STRAP ASSY , CRT
A25A02D7
Part# Description
009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS
014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-02 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01989 CONNECTOR AND, CABLE ASSEMBLY
095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL
A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
152-00335 WEDGE, YOKE SPACER,POSITIONER
192-00916 LENS, IR
206-03369 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY , CRT
A25A02D74
Part# Description
009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS
014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-06 CABINET REAR, TV, MOLDED PLASTIC
020-04330-35 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-01989 CONNECTOR AND, CABLE ASSEMBLY
095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL
A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY
LGA21A22DM84
Part# Description
009-01992-01 MODULE, MAIN, 19, 20V WITH MTS, GA1 CHASSIS
001-00224-06 ANTENNA, DIPOLE
014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO
014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V
MONAURAL, STEREO
020-04330-31 COIL, DEGAUSSER
046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01369 SPEAKER, OVAL, 6 X 9 CM
050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP
124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446
152-00335 WEDGE, YOKE SPACER, POSITIONER
192-00917 LENS, IR
206-03381 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-14323 BALUN ASSEMBLY
A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR
A-18693 CRT ASSEMBLY, WITH DEFLECTION YOKE
A-18695-09 GND STRAP ASSY , CRT
