NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA1 MODULE PARTS LIST
CM150 4-1 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01
I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01
ABCDEFGHIJKLMNOP 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION
ABCDEFGHIJKLMNOP 3Y3 058-00643-04 PLUG, MULTIPRONG, 4 POSITION
OP 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT/
OP 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT/
ABCDEFGHIJKLMNOP ANT0001 A-18578 ISOLATOR ASSY, SHIELDED BOX/
ABIJ C0801 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABIJ C0802 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO
ABIJ C0803 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
ABIJ C0806M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC
CHIP
ABIJ C0820 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO
CDEFGHKLMNOP C0820 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO
ABCDEFGHIJKLMNOP C0821M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
CDEFGHKLMNOP C0830 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDEFGHKLMNOP C0831 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDEFGHKLMNOP C0832 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
CDEFGHKLMNOP C0833 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO
CDEFKLMN C0850 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDEFKLMN C0851 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDEFKLMN C0852 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
CDEFKLMN C0853 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO
ABIJ C1202M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP
ABCDEFIJKLMN C1208 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO
ABCDEFIJKLMN C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
GHOP C1211 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO
ABCDEFGHIJKLMNOP C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1215M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1216M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDEFGHIJKLMNOP C1218M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1219M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO
ABCDEFGHIJKLMNOP C1221M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
ABCDEFGHIJKLMNOP C1223M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1224M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1225M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1226M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1227M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1228M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C1231M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO
ABCDEFGHIJKLMNOP C1234M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C1236M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDKL C1401M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
CDKL C1403 022-08227-15A CAP, 0.22 MFD 5% 50V, POLYESTER
CDKL C1404 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDKL C1409 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDKL C1410 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDKL C1411 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
CDKL C1412M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDKL C1415 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
CDKL C1416 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDKL C1417 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
CDKL C1418M 022-08366-13A CAP, 2,700 PFD 10% 50V, CERAMIC CHIP
CDKL C1420M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDKL C1423 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFKLMN C1432 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLYESTER
CDEFGHKLMNOP C1433 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLYESTER
CDEFKLMN C1450 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHKLMNOP C1451 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFKLMN C1490 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2102 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2104 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
ABCDEFGHIJKLMNOP C2105 022-08312-06A CAP, 3.3 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2107M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2206 022-08227-23A CAP, 1 MFD 5% 50V, POLYESTER
ABCDEFGHIJKLMNOP C2207M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2208 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO
ABCDEFGHIJKLMNOP C2209M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2212 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDGHIJKLOP C2217 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
EFMN C2217 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDGHIJKLOP C2218 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
EFMN C2218 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2220M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2225M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP
EFGHMNOP C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDIJKL C2230M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2234M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2237M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2240M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2241M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C2250M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C3202 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3203 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO
ABCDEFGHIJKLMNOP C3205 022-08229-21 CAP, 0.0075 MFD 3% 1600VDC, POLYPROP
IJKLMNOP C3206 022-08386-01 CAP, 270 PFD 10% 2000V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3207 022-08317-08 CAP, 10 MFD 20% 250V, ELECTRO
ABCDEFGHIJKLMNOP C3208 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3209 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3210 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3211 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3214 022-07774-16 CAP, 0.022MFD 10% 100V, POLYESTER
ABCDEFGHIJKLMNOP C3216 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO
ABCDEFGHIJKLMNOP C3217 022-07876-19 CAP, 0.39 MFD 5% 250V, POLYESTER
ABCDEFGHIJKLMNOP C3218 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C3219 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER
ABCDEFGHIJKLMNOP C3220 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C3221 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC
ABCDEFGHIJKLMNOP C3222 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C5100 022-08318-04A CAP, 1 MFD 20% 350V, ELECTRO
ABCDEFGHIJKLMNOP C5101M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C5102M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C5103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C5104 022-07523-01B CAP, 0.01 MFD +80 % & -20 % 2000V,
CERAMIC DISC
ABCDEFGHIJKLMNOP C5105 022-07773-08 CAP, 0.0047 MFD 5% 100V, POLYESTER
ABCDEFGHIJKLMNOP C6001M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C6002M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C6003M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP C6004 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOP C6005M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP
