NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA1 MODULE PARTS LIST
CM150 4-3 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01
I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01
CDEFKLMN IC0850 221-01163 INTEGRATED CKT, AUDIO PWR AMP, W/ VOL
CTRL
CDKL IC1400 221-00907 IC , STEREO DECODER
ABCDEFGHIJKLMNOP IC2101 083-09299-02 STRIP, EDGE PROTECTOR, NYLON
ABCDEFGHIJKLMNOP IC2101 221-00903 INTEGRATED CKT, VERTICAL DEFLECTION
ABCDEFGHIJKLMNOP IC3201 221-00166-09 INTEGRATED CKT, 9 VOLT, 500MA, LINEAR
REGULATOR
ABCDEFGHIJKLMNOP IC6000 126-03446-02 SHIELD, EMI, MICROPROCESSOR
ACEFGIKMO IC6000 221-01164-01 IC , 8-BIT MICROCOMPUTER, WITH CAPTION
BDHJLNP IC6000 221-01164-02 IC , 8-BIT MICROCOMPUTER, WITH LIGHT DE
ABCDEFGHIJKLMNOP IC6001 221-00745-04 IC , 4K BIT SERIAL EEPROM
ABCDEFGHIJKLMNOP IC6002 221-01177A IC , SYSTEM RESET
EFMN IC9700 162-00018 PHOTO-OPTIC, COUPLER , INTERRUPTER
EFGHMNOP IC9701 162-00018 PHOTO-OPTIC, COUPLER , INTERRUPTER
EFGHMNOP IC9702 162-00040-01 PHOTOCOUPLER
ABCDEFGHIJKLMNOP ICX2200 221-01165 IC , I2C BUS CONTROL NTSC
ABCDEFGHIJKLMNOP ICX3401 019-00838-05 CLIP, STAND-OFF
ABCDEFGHIJKLMNOP ICX3401 223-00040-01 INT CKT, THICK FILM, HYBRID, VOLTAGE
REGULATOR
ABCDEFGHIJKLMNOP ICX3402 221-00167-01A IC , VOLTAGE REGULATOR, 5V 100MA
ABCDEFGHIJKLMNOP IR6000 162-00046 IR DETECTOR
EFMN J0001 A-18577 JACK ASSEMBLY, 3 JACK
GHOP J0001 A-18577-01 JACK ASSEMBLY, 2 JACK
ABCDEFGHIJKLMNOP J0001M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDEFGHIJKLMNOP J0002M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDEFGHIJKLMNOP KX3401 195-00161 RELAY, SPST, 12 VDC COIL
ABCDEFGHIJKLMNOP L1200 020-04506 COIL, RCF, FIXED, SHIELDED
ABCDEFGHIJKLMNOP L1201 020-04277-39A COIL, 10 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L1202 020-03907-12A COIL, 10 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L1203 020-04277-23A COIL, 12 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L1204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER
ABCDEFGHIJKLMNOP L1205 020-04278B COIL, RCF, TUNABLE, 7.0 MM
ABCDEFGHIJKLMNOP L1206 020-04277-09A COIL, 0.82 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L1208 020-03907-25A COIL, 120 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L2202 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L3201 020-04458 COIL, LINEARITY/
ABCDEFGHIJKLMNOP L3202 149-00576-01 CORE, FERRITE BEAD
ABCDEFGHIJKLMNOP L5100 020-03907-28A COIL, 220 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L5102 149-00583-01 CORE, FERRITE BEAD
ABCDEFGHIJKLMNOP L6000 020-03907-24A COIL, 100 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L6001 020-04129-21 COIL, 12 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L6002 091-02053 WIRE, SOLID, BARE, 22 GA COPPER
ABCDEFGHIJKLMNOP L6003 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L6004 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP L6005 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED
ABCDEFGHIJKLMNOP LX3401 095-03868-04 TRANSFORMER, LINE CHOKE, COMMON MODE
ABCDEFGHIJKLMNOP LX3402 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED
EFMN MTS0001 009-01867 MODULE, SOUND MULTIPLEXING DECODER,
USA
ABCDEFGHIJKLMN P0025C 050-01666-11 CONNECTOR&CABLE, ASSY, 2.5MM, 5
CONTACT, 2 UP
ABCDEFGHIJKLMN P0025F 050-01665-11 CONNECTOR&CABLE, ASSY, 2.5MM, 4
CONTACT, 2 UP
ABCDEFGHIJKLMN P0049G 058-00526-05 PLUG, 0.098P 5 CONTACT
ABIJ P0094M 058-00526-02 PLUG, 0.098P 2 CONTACT
CDEFGHKLMN P0094S 058-00526-04 PLUG, 0.098P 4 CONTACT
ABCDEFGHIJKLMNOP Q1203 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q1204 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q1205 121-01261A TRANSISTOR, NPN, SILICON
CDKL Q1400 121-01311A TRANSISTOR, PNP, SILICON
EFGHMNOP Q1402 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q2201 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q2202 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q2203 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q2204 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q2205 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q3201 121-01290 TRANSISTOR, NPN, SILICON
EF Q3202 121-01148 TRANSISTOR, NPN, SILICON, H.O.T., 5A
ABCDGHIJKLMNOP Q3202 121-01383 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q3203 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOP Q5101 121-01334 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q5102 121-01334 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q5103 121-01334 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q6001 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP Q6002 121-01310A TRANSISTOR, NPN, SILICON
CDEFGHKLMNOP Q6003 121-01310A TRANSISTOR, NPN, SILICON
EFMN Q9700 121-01310A TRANSISTOR, NPN, SILICON
EFMN Q9701 121-01310A TRANSISTOR, NPN, SILICON
EFGHMNOP Q9702 121-01310A TRANSISTOR, NPN, SILICON
EFGHMNOP Q9703 121-01310A TRANSISTOR, NPN, SILICON
EFGHMNOP Q9704 121-01310A TRANSISTOR, NPN, SILICON
EFGHMNOP Q9705 121-01310A TRANSISTOR, NPN, SILICON
EFGHMNOP Q9706 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOP QX3402 121-01310A TRANSISTOR, NPN, SILICON
ABIJ R0801M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W
ABIJ R0802M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABIJ R0803 063-10235-16 RESISTOR, FILM, 4.7 OHM 5% 1/4W
ABIJ R0820 063-10832-24B RESISTOR, FILM, 10 OHM 5% 1W
CDEFGHKLMNOP R0820 063-11156-07B RESISTOR, FILM, 2 OHM 5% 1W
CDEFGHKLMNOP R0831 063-10235 RESISTOR, FILM, 1 OHM 5% 1/4W
CDEFGHKLMNOP R0832M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
CDEFKLMN R0851 063-10235 RESISTOR, FILM, 1 OHM 5% 1/4W
CDEFKLMN R0852 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDEFIJKLMN R1209 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
GHOP R1210M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
ABCDEFGHIJKLMNOP R1211M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1212M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1213M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1216M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1217M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1218M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1219 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDEFGHIJKLMNOP R1220M 063-11059-95A RESISTOR, CHIP, 82K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1221 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
ABCDEFGHIJKLMNOP R1222M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1223 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W
ABCDEFGHIJKLMNOP R1224M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1225M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1226M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1227M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1228 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W
ABCDEFGHIJKLMNOP R1229M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1230M 063-11059-13A RESISTOR, CHIP, 33 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1232M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1233M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1234M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R1235M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W
CDKL R1404M 063-11059-67A RESISTOR, CHIP, 5.6K OHM 5% 1/10W
CDKL R1407M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W
CDKL R1409M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W
CDKL R1410M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W
CDKL R1411M 063-11059-76A RESISTOR, CHIP, 13K OHM 5% 1/10W
CDKL R1412 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
EFGHMNOP R1420M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFGHMNOP R1421 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
EFMN R1423 063-11087-46 RESISTOR, FILM, 82 OHM 5% 1/2W
CDKL R1423 063-11087-48 RESISTOR, FILM, 100 OHM 5% 1/2W
CDEFKLMN R1450M 063-11059-75A RESISTOR, CHIP, 12K OHM 5% 1/10W
