NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA1 MODULE PARTS LIST
CM150 4-5 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01
I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01
ABCDEFGHIJKLMNOP R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6037M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6038 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKLMNOP R6039 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKLMNOP R6040M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKLMNOP R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKLMNOP R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6050M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFIJKLMN R6051 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
EFMN R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDIJKL R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFIJKLMN R6053M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFIJKLMN R6054M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFMN R6055 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
EFMN R6056 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
CDEFGHKLMNOP R6058 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W
ABCDEFGHIJKLMNOP R6059M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6060M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFMN R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
CDKL R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
GHOP R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFMN R6062M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFMN R6063M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKLMNOP R6080M 063-11060-14A RESISTOR, CHIP, 510K OHM 5% 1/10W
EFGHMNOP R9701 091-02053 WIRE, SOLID, BARE, 22 GA COPPER
EFGHMNOP R9703 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W
EFGHMNOP R9704 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W
EFMN R9705 063-10236-14 RESISTOR, FILM, 56K OHM 5% 1/4W
EFMN R9706 063-10235-68 RESISTOR, FILM, 680 OHM 5% 1/4W
EFMN R9707M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W
EFGHMNOP R9708 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W
EFMN R9709M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
EFMN R9710 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
EFMN R9711M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
EFGHMNOP R9712 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W
EFMN R9714M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
EFMN R9715M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
EFGHMNOP R9717 063-10236-14 RESISTOR, FILM, 56K OHM 5% 1/4W
EFGHMNOP R9718 063-10235-68 RESISTOR, FILM, 680 OHM 5% 1/4W
EFGHMNOP R9720M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W
EFGHMNOP R9721M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
EFGHMNOP R9724M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
EFGHMNOP R9725M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFGHMNOP R9726M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
EFGHMNOP R9727M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
EFGHMNOP R9728 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W
EFGHMNOP R9729M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W
EFGHMNOP R9730 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W
EFGHMNOP R9731M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
EFGHMNOP R9732M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W
EFGHMNOP R9734M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
EFGHMNOP R9735M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
EFGHMNOP R9736M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W
EFGHMNOP R9737M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
EFGHMNOP R9738 063-11007-06 CONTROL, ROTARY, TRIMMER
EFGHMNOP R9739M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
EFGHMNOP R9740 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W
GHOP R9745 063-10235-65 RESISTOR, FILM, 510 OHM 5% 1/4W
EFMN R9745 063-11007-29 CONTROL, ROTARY, TRIMMER
ABCDEFGHIJKLMNOP RX3002M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W
ABCDEFGHIJKLMNOP RX3003 063-10233-86 RESISTOR, FILM, 3.9K OHM 2% 1/4W
ABCDEFGHIJKLMNOP RX3004M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W
ABCDEFGHIJKLMNOP RX3401 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M
OHM 20% 1/2W
ABCDEFGH RX3402 063-10710A RESISTOR, THERMISTOR
IJKLMNOP RX3402 063-11119 RESISTOR, THERMISTOR, DEGAUSSER
ABCDEFGHIJKLMNOP RX3403 063-10449-24B RESISTOR, WIREWOUND, 1 OHM 5% 7W
ABCDEFGHIJKLMNOP RX3404 063-10458-92A RESISTOR, WIREWOUND, 680 OHM 5% 10W
ABCDEFGHIJKLMNOP RX3405 063-10458-92A RESISTOR, WIREWOUND, 680 OHM 5% 10W
ABCDEFGHIJKLMNOP RX3406 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W
ABCDEFGHIJKLMNOP RX3407 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W
ABCDEFGHIJKLMNOP RX3408 063-10244-20 RESISTOR, FILM, 100K OHM 5% 1/2W
ABCDEFGHIJKLMNOP RX3409 063-11087-96 RESISTOR, FILM, 10K OHM 5% 1/2W
ABCDEFGHIJKLMNOP RX3410 063-10236-38 RESISTOR, FILM, 560K OHM 5% 1/4W
ABCDEFGHIJKLMNOP RX3411 063-10559-40 RESISTOR, FILM, 47 OHM 5% 1/4W
ABCDEFGHIJKLMNOP RX3412 063-10442-32A RESISTOR, WIREWOUND, 2.2 OHM 5% 5W
ABCDEFGHIJKLMNOP RX3413 063-10476-78A RESISTOR, WIREWOUND, 180 OHM 5% 20W
ABCDEFGHIJKLMNOP RX3414 063-10244-06 RESISTOR, FILM, 27K OHM 5% 1/2W
ABCDEFGHIJKLMNOP RX3415 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W
ABCDEFGHIJKLMNOP RX3416 063-10836-82B RESISTOR, FILM, 2.7K OHM 5% 2W
ABCDEFGHIJKLMNOP RX3417 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W
ABCDEFGHIJKLMNOP RX3418 063-11164-88B RESISTOR, FILM, 4.7K OHM 5% 3W
ABCDEFGHIJKLMNOP RX3419 063-11164-88B RESISTOR, FILM, 4.7K OHM 5% 3W
ABCDEFGHIJKLMNOP RX3420 063-10235-24 RESISTOR, FILM, 10 OHM 5% 1/4W
ABCDEFGHIJKLMNOP RX5126 063-10833B RESISTOR, FILM, 15K OHM 5% 1W
ABCDEFGHIJKLMNOP RX5127 063-10833B RESISTOR, FILM, 15K OHM 5% 1W
ABCDEFGHIJKLMNOP RX5128 063-10833B RESISTOR, FILM, 15K OHM 5% 1W
EFGHMNOP RX9702 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M
OHM 20% 1/2W
ABCDEFGHIJKLMNOP SW0001 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP SW0002 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP SW0003 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP SW0004 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP SW0005 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP SW0006 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,
SPST
ABCDEFGHIJKLMNOP T3201 095-04525 TRANSFORMER, HORIZONTAL DRIVER/
EFGHIJKLMNOP TU6000 175-02720 TUNER, VARACTOR, 181 CHANNEL, SINGLE
IC, WORLD STAN
ABCDEFGHIJKLMNOP TX3202 095-04376-02 SWEEP XFMR, COLOR, FINAL
EFGHMNOP TX9701 095-04526 TRANSFORMER, ISOLATION
ABCDEFGHIJKLMNOP U1200 224-00139-01A FILTER, 4.5 MHZ CERAMIC BANDPASS
ABCDEFGHIJKLMNOP U1201 224-00160 FILTER, SURFACE ACOUSTIC WAVE
ABCDEFGHIJKLMNOP U1202 224-00023A CERAMIC FILTER , 4.5 MHZ TRAP
GHOP W0075 301-99282P020D WIRE, STRANDED, SINGLE CONDUCTOR, 22
GA WHITE
CDKL ZD1400 103-00279-15A DIODE, ZENER, 7.5V 0.5W
EFMN ZD1400 103-00279-18A DIODE, ZENER, 9.1V 0.5W
ABCDEFGHIJKLMNOP ZD3206 103-00336-10A DIODE, ZENER, 5.1V 0.5W
ABCDEFGHIJKLMNOP ZD6001 103-00279-36A DIODE, ZENER, 33V 0.5W
EFGHMNOP ZD9701 103-00279-18A DIODE, ZENER, 9.1V 0.5W
EFMN ZD9702 103-00279-18A DIODE, ZENER, 9.1V 0.5W
ABCDEFGHIJKLMNOP ZDX3408 103-00301-16A DIODE, ZENER, 12V 1W
ABCDEFGHIJKLMNOP ZDX3412 103-00336-18A DIODE, ZENER, 9.1V 0.5W
