NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA2 MODULE PARTS LIST
CM150 4-7 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01
G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01
IJ 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT
ABCDEFGHIJKL 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION
DHIJKL 3Y3 058-00546-04 PLUG, MULTIPRONG, 4 POSITION
IJ 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT
IJ 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT
ABL C0801 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABL C0802 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO
ABL C0803 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABL C0804M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABL C0805 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO
ABL C0806M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
CDEFGHIJK C0820 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO
CDEFGHIJK C0821M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
CDEFGHIJK C0830 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDEFGHIJK C0831 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDEFGHIJK C0832 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
CDEFGHIJK C0833 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO
CDEFGHIJK C0850 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDEFGHIJK C0851 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDEFGHIJK C0852 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
CDEFGHIJK C0853 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO
ABL C1202M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1208 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO
ABCDEFGHIJKL C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1215M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1216M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDEFGHIJKL C1218M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1219M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO
ABCDEFGHIJKL C1221M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDEFGHIJKL C1223M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1224M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1225M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1226M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C1227M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1228M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C1231M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO
ABCDEFGHIJKL C1234M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C1236M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDEFGK C1401M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
CDEFGK C1403 022-08227-15A CAP, 0.22 MFD 5% 50V, POLY
CDEFGK C1404 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGK C1409 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
CDEFGK C1410 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGK C1411 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
CDEFGK C1412M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDEFGK C1415 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
CDEFGK C1416 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
CDEFGK C1417 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
CDEFGK C1418M 022-08366-13A CAP, 2,700 PFD 10% 50V, CERAMIC CHIP
CDEFGK C1420M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
CDEFGK C1423 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHIJK C1432 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHIJK C1433 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHIJK C1435M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
CDEFGHIJK C1437M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP
CDEFGHIJK C1440 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLY
CDEFGHIJK C1441 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLY
CDEFGHIJK C1450 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHIJK C1451 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
CDEFGHIJK C1490 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2102 022-08312-06A CAP, 3.3 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2103M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2104 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDEFGHIJKL C2105 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2107M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2206 022-08227-23A CAP, 1 MFD 5% 50V, POLY
ABCDEFGHIJKL C2207M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C2208 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO
ABCDEFGHIJKL C2209M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP
ABCDEFGHIJKL C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2212 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2217 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2218 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2220M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C2221M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2225M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP
CDEFGHIJK C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2230 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO
ABCDEFGHIJKL C2231 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO
ABL C2232M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP
ABCDEFGHIJKL C2234M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2237M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2240M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2241M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2250M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2257M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C2601 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY
ABCDEFGHIJKL C2602 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDEFGHIJKL C2603 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C2604 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO
ABCDEFGHIJKL C3209 022-07786-17C CAP, 2200 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKL C3211 022-07774-16 CAP, 0.022MFD 10% 100V, POLY
ABCDEFGHIJKL C3214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDEFGHIJKL C3215 022-08257-08A CAP, 470 PFD 10% 50V, CERAMIC DISC
ABCDEFGHIJKL C3232 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC
ABCDEFGHIJKL C3237 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC
EF C3248 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDEFGHIJKL C3269 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKL C3271 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKL C3419 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKL C3421 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC
ABCDEFGHIJKL C3428 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDEFHIJKL C5101M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
G C5101M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP
ABCDEFHIJKL C5102M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
G C5102M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP
ABCDEFHIJKL C5103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP
G C5103M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP
ABCDEFGHIJKL C5104 022-07523-01B CAP, 0.01 MFD +80% & -20% 2000V, CERAMIC DI
ABCDEFGHIJKL C5109 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC
GA2 MODULE PARTS
