NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA2 MODULE PARTS LIST
CM150 4-11 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01
G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01
ABCDEFGHIJKL R3421 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W
ABCDEFGHIJKL R3422M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKL R3423 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDEFGHIJKL R5101M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFGHIJKL R5102M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFGHIJKL R5103M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFGHI R5104M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W
JKL R5104M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDEFGHI R5105M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W
JKL R5105M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDEFGHI R5106M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W
JKL R5106M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDEFGHI R5107M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W
JKL R5107M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDEFGHI R5108M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W
JKL R5108M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDEFGHI R5109M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W
JKL R5109M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
G R5113M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFHIJKL R5113M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
G R5114M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFHIJKL R5114M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
G R5115M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDEFHIJKL R5115M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
ABCDEFGHIJKL R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDEFGHIJKL R5117 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDEFGHIJKL R5118 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDEFGHIJKL R5119 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDEFGHIJKL R5120 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDEFGHIJKL R5121 063-10244-28 RESISTOR, FILM, 220K OHM 5% 1/2W
ABCDEFHIJKL R5122 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
G R5122 063-11087-72 RESISTOR, FILM, 1.0K OHM 5% 1/2W
ABCDEFGHIJKL R6001M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKL R6002M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKL R6003M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKL R6004M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W
ABCDEFGHIJKL R6005 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDEFGHIJKL R6006M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDEFGHIJKL R6007M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKL R6008M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKL R6009M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGHIJKL R6012M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W
ABCDEFGHIJKL R6013M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W
ABCDEFGHIJKL R6015M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGHIJKL R6016M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGKL R6017M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGKL R6018M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGKL R6020M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W
ABCDEFGKL R6021M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGKL R6022M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGKL R6023M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGKL R6024M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W
ABCDEFGKL R6025M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W
ABCDEFGHIJKL R6027 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDEFGKL R6028 063-10235-60 RESISTOR, FILM, 330 OHM 5% 1/4W
ABCDEFGKL R6029 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
ABCDEFGHIJKL R6030 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKL R6031M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDEFGHIJKL R6032M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W
ABCDEFGHIJKL R6033M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDEFGHIJKL R6034M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDEFGHIJKL R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDEFGHIJKL R6037M 063-11059-81A RESISTOR, CHIP, 22K OHM 5% 1/10W
CDEFGHIJK R6038 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKL R6039 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKL R6040M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDEFGHIJKL R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKL R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKL R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDEFGHIJKL R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKL R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKL R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKL R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKL R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDEFGHIJKL R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDEFGHIJKL R6050M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
CDEFGHIJK R6051 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
HIJ R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
CDEFGHIJK R6053M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
HIJ R6054M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
HIJ R6055 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
HIJ R6056 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
CDEFGHIJK R6058M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W
CDEFGHIJK R6059M 063-11059-76A RESISTOR, CHIP, 13K OHM 5% 1/10W
CDEFGHIJK R6060M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
CDEFGHIJK R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
HIJ R6062M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
HIJ R6063M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
HIJ R6069M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W
HIJ R6070M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W
ABCDEFGHIJKL R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDEFGHIJKL R6080M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDEFGHIJKL RX2601 063-10243-96 RESISTOR, FILM, 10K OHM 5% 1/2W
ABCDEFGHIJKL RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM 1% 1/4W
ABCDEFGHIJKL RX3009 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W
ABCDEFGHIJKL RX3010 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W
ABCDGHIJKL RX3015 063-10236-12 RESISTOR, FILM, 47K OHM 5% 1/4W
EF RX3015 063-10236-16 RESISTOR, FILM, 68K OHM 5% 1/4W
ABCDEFGHIJKL RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W
ABCDEFGHIJKL RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W
EF RX3202 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDEFGHIJKL RX3204 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDEFGHIJKL RX3205 063-10565 RESISTOR, FILM, 1 OHM 5% 1/2W
ABCDEFGHI RX3237 063-10420-28 RESISTOR, WIREWOUND, 1.5 OHM 5% 2W
JKL RX3237 063-10420-37 RESISTOR, WIREWOUND, 3.6 OHM 5% 2W
ABCDEFGHIJKL RX3242 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W
ABCDEFGHI RX3261 063-10460-38A RESISTOR, WIREWOUND, 3.9 OHMS 10% 10W
JKL RX3261 063-10460-44A RESISTOR, WIREWOUND, 6.8 OHM 10% 10W
ABCDEFGHIJKL RX3263 063-10244-04 RESISTOR, FILM, 22K OHM 5% 1/2W
ABCDEFGHIJKL RX3264 063-10832-69B RESISTOR, FILM, 750 OHM 5% 1W
ABCDEFGHIJKL RX3277 063-10565-10 RESISTOR, FILM, 2.7 OHM 5% 1/2W
ABCDEFGHIKL RX3299 063-10565-28C RESISTOR, FILM, 15 OHM 5% 1/2W
ABCDEFGHIJKL RX3400 063-11182 RESISTOR, CARBON COMPOSITION, 5.6M OHM
20% 1/2W
ABCDEFGHIJKL RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68 OHM 10% 5W
ABCDEFGHIJKL RX3403 063-10428-06 RESISTOR, WIREWOUND, 0.18 OHM 5% 3W
ABCDEFGHIJKL RX3404 063-10244-26 RESISTOR, FILM, 180K OHM 5% 1/2W
ABCDEFGHIJKL RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W
ABCDEFGHIJKL RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5% 1W
ABCDEFGHIJKL RX3408 063-10243-32 RESISTOR, FILM, 22 OHM 5% 1/2W
ABCDEFGHIJKL RX3409 063-11110-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W
ABCDEFGHIJKL RX3411 063-10837B RESISTOR, FILM, 15K OHM 5% 2W
ABCDEFGHIJKL RX3415 063-10710A RESISTOR, THERMISTOR
ABCDEFGHIJKL RX3416 063-11160-60B RESISTOR, FILM, 330 OHM 5% 2W
ABCDEFGHIJKL RX3417 063-10243-68 RESISTOR, FILM, 680 OHM 5% 1/2W
ABCDEFGHIJKL RX3420 063-11164-20B RESISTOR, FILM, 6.8 OHM 5% 3W
ABCDEFGHIJKL RX3424 063-11164-08B RESISTOR, FILM, 2.2 OHM 5% 3W
ABCDEFGHIJKL RX5126 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W
