NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA3 MODULE PARTS LIST
CM150 4-13 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041
ABCDE 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT
ABCDE 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION
ABCDE 3Y3 058-00643-04 PLUG, MULTIPRONG, 4 POSITION
ABCDE 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT
ABCDE 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT
ABCDE C0841 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO
ABCDE C0842 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C0843 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO
ABCDE C0851 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C0852 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C0853 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C0854 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO
ABCDE C0855M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP
ABCDE C0861 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C0862 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C0863 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C0864 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO
ABCDE C0865M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP
ABCDE C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP
ABCDE C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDE C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDE C1215M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1216M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C1218M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1219M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO
ABCDE C1221M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C1223M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1224M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C1225M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1226M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1227M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C1228M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDE C1231M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDE C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO
ABCDE C1234M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP
ABCDE C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO
ABCDE C1236M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C1401M 022-08370-22A CAP, 15,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C1402M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP
ABCDE C1403M 022-08370-22A CAP, 15,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C1404M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP
ABCDE C1406M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C1408 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCD C1410 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1413 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C1414 022-07669-15A CAP, 10 MFD 10% 50V, ELECTRO
ABCDE C1415 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C1416 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO
ABCDE C1417 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO
ABCDE C1418 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C1419 022-07669-14A CAP, 3.3 MFD 10% 50V, ELECTRO
ABCDE C1420 022-08049-13A CAP, 0.012 MFD 10% 50V, POLY
ABCDE C1421 022-08257-21A CAP, 5600 PFD 10% 50V, CERAMIC DISC
ABCDE C1422 022-08049-20A CAP, 0.047 MFD 10% 50V, POLY
ABCDE C1424 022-08257-17A CAP, 2700 PFD 10% 50V, CERAMIC DISC
ABCDE C1425 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1426 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO
ABCDE C1427 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO
ABCDE C1428 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1430 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C1431M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C1432 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1433M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C1436 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C1440 022-08227A CAP, 0.01 MFD 5% 50V, POLY
ABCDE C1442 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1443 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDE C1444 022-08227A CAP, 0.01 MFD 5% 50V, POLY
ABCDE C1445 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C1446 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDE C1447 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO
ABCDE C1448 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C1449 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C2106 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C2107 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2108 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
ABCDE C2114 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C2115 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C2116 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C2119 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP
ABCDE C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDE C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDE C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDE C2207M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C2208 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C2209M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP
ABCDE C2210M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP
ABCDE C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO
ABCDE C2212 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2217 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDE C2218 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO
ABCDE C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C2220M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C2221M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP
ABCDE C2225M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP
ABCDE C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDE C2237M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP
ABCDE C2245 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO
ABCDE C2257M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP
ABCDE C2260 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2261 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO
ABCDE C2270 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY
ABCDE C2271 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO
ABCDE C2272 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY
ABCDE C2290 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO
ABCDE C2294M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP
ABCDE C2299M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C2901M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C2902M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP
ABCDE C2903M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP
ABCDE C2904M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP
ABCDE C2905 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2908 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO
ABCDE C2951 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO
ABCDE C3209 022-07786-17C CAP, 2200 PFD 10% 500V, CERAMIC DISC
ABCDE C3211 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY
ABCDE C3214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP
ABCDE C3215 022-08257-08A CAP, 470 PFD 10% 50V, CERAMIC DISC
GA3 MODULE PARTS
