NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA3 MODULE PARTS LIST
CM150 4-15 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041
ABCDE D2203 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE D2206 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE D2215 103-00471A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE D3410 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE D3410 149-00576-01 CORE, FERRITE BEAD
ABCDE D3411 103-00417-03A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE D3411 149-00576-01 CORE, FERRITE BEAD
ABCDE D3412 103-00417-03A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE D6001 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE D6002 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE DL2200 223-00045 INTD CKT PKG, NTSC COMB FILTER, HYBRID
ABCDE DX2101 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE DX2102 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE DX2103 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE DX3005 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE
ABCDE DX3006 103-00344-04A DIODE, LOW VOLTAGE GENERAL
BD DX3201 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDE DX3204 103-00471A DIODE, LOW VOLTAGE GENERAL, SILICON
BD DX3207 103-00305-01A DIODE, HIGH VOLTAGE GENERAL, SILICON
BD DX3207 149-00454 CORE, FERRITE BEAD
ABCDE DX3260 103-00284A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE DX3273 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE DX3287 103-00326A DIODE, LOW VOLTAGE GENERAL, SILICON
BD DX3288 103-00344-04A DIODE, LOW VOLTAGE GENERAL
ABCDE DX3401 212-00172-04 RECTIFIER NTWK , BRIDGE, 600V/4A
ABCDE DX3405 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON
ABCDE DX3406 103-00344-02A DIODE, LOW VOLTAGE GENERAL
ABCDE DX3407 103-00344-02A DIODE, LOW VOLTAGE GENERAL
ABCDE DX3409 103-00344-02A DIODE, LOW VOLTAGE GENERAL
ABCDE EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV DC
ABCDE FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP 250V
ABCDE FX3402 136-00148-23 FUSE, NORMAL LAG, 3 AMP 250V
ABCDE FX3403 136-00148-03 FUSE, NORMAL LAG, 2 AMP 250V
ABCDE IC0804 221-00598-01 IC, AUDIO POWER AMPLIFIER, 3.5W, 2 CHANNEL
ABCDE IC1400 221-01127 IC, MTS STEREO DECODER/VOL.LIMITER AND
ABCDE IC2001 221-01171 IC, AUDIO/VIDEO SWITCH, 2 CHAN/2 POSIT
ABCDE IC2100 221-00992-01 IC, VERTICAL DEFLECTION
ABCDE IC6000 126-03446-02 SHIELD, EMI, MICROPROCESSOR/
ABCDE IC6000 221-01305-01 IC, 8-BIT MICROCOMPUTER
ABCDE IC6001 221-00745-04 IC, 4K BIT SERIAL EEPROM
ABCDE IC6002 221-01177A IC, SYSTEM RESET
ABCDE ICX2200 221-01165 IC, I2C BUS CONTROL NTSC
ABCDE ICX3431 223-00028 IC PKG, HYBRID, VOLTAGE REGULATOR
ABCDE ICX3441 221-00213-09 IC, 9 VOLT, 1 AMP, LINEAR, REGULATOR
ABCDE ICX3442 221-00167-01A IC, VOLTAGE REGULATOR, 5V 100MA
ABCDE J0002M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE J0004M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE J0005M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE J0006M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE JM0008 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE KX3401 195-00161 RELAY, SPST, 12 VDC COIL
ABCDE L1200 020-04506 COIL, RCF, FIXED, SHIELDED
ABCDE L1201 020-04277-39A COIL, 10 MICROHENRY, RCF, FIXED
ABCDE L1202 020-03907-12A COIL, 10 MICROHENRY, RCF, FIXED
ABCDE L1203 020-04277-23A COIL, 12 MICROHENRY, RCF, FIXED
ABCDE L1204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER
ABCDE L1205 020-04278B COIL, RCF, TUNABLE, 7.0 MM
ABCDE L1206 020-04277-09A COIL, 0.82 MICROHENRY, RCF, FIXED
ABCDE L1208 020-03907-25A COIL, 120 MICROHENRY, RCF, FIXED
ABCDE L2203 020-04129-22 COIL, 15 MICROHENRY, RCF, FIXED
ABCDE L2901 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED
ABCDE L3407 020-04462-18A COIL, 33 MICROHENRY, RCF, FIXED
ABCDE L5100 020-03907-28A COIL, 220 MICROHENRY, RCF, FIXED
ABCDE L5102 149-00583-01 CORE, FERRITE BEAD
ABCDE L6000 020-03907-24A COIL, 100 MICROHENRY, RCF, FIXED
ABCDE L6001 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED
ABCDE L6002 020-04277-70A COIL, 1.8 MICROHENRY, RCF, FIXED
ABCDE L6003 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED
ABCDE L6004 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED
ABCDE L6005 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED
ABCDE L6007 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED
BD LX3201 020-04530 COIL, CHOKE
ABCDE LX3210 149-00540-01 CORE, FERRITE
BD LX3262 020-04073-01 COIL, RCF, LINEARITY
ACE LX3262 020-04073-03 COIL, RCF
ABCDE LX3401 095-04285 TRANSFORMER, LINE CHOKE
ABCDE LX3405 020-04405-48 COIL, 100 MICROHENRY, RCF, FIXED
ABCDE LX3410 149-00576-01 CORE, FERRITE BEAD
ABCDE Q0800 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q1203 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q1204 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q1205 121-01261A TRANSISTOR, NPN, SILICON
ABCDE Q1401 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q1402 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q1403 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q1404 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q1405 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q2202 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q2203 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q2204 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q2205 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q2206 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q2209 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q2210 121-01311A TRANSISTOR, PNP, SILICON
ABCDE Q3202 121-01310A TRANSISTOR, NPN, SILICON
BD Q3203 121-01264-01A TRANSISTOR, NPN SILICON
ABCDE Q3206 121-01264-01A TRANSISTOR, NPN SILICON
ABCDE Q3402 121-01340A TRANSISTOR, NPN, SILICON
ABCDE Q3404 121-01102A TRANSISTOR, PNP, SILICON
ABCDE Q5101 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDE Q5102 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDE Q5103 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDE Q6001 121-01310A TRANSISTOR, NPN, SILICON
ABCDE Q6002 121-01310A TRANSISTOR, NPN, SILICON
BD QX3201 121-01237 TRANSISTOR, PNP, SILICON, 5A 80V
ABCD QX3208 121-01383 TRANSISTOR, NPN, SILICON
ABCDE QX3401 121-01348 TRANSISTOR, NPN, SILICON, 80V/1A
ABCDE R0843 063-10235-60 RESISTOR, FILM, 330 OHM 5% 1/4W
ABCDE R0851M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R0852M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W
ABCDE R0853 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W
ABCDE R0854M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R0861M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R0862M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W
ABCDE R0863 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W
ABCDE R0864M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R1209M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R1210M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W
ABCDE R1211M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R1212M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R1213M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R1214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R1216M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R1217M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R1218M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R1219M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W
ABCDE R1220 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W
ABCDE R1221M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
