NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.
GA3 MODULE PARTS LIST
CM150 4-17 GA - MODULE PARTS
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041
ABCDE R2914 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W
ABCDE R2916 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDE R2920 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
BD R3201 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W
BD R3203 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
BD R3212 063-10236-28 RESISTOR, FILM, 220K OHM 5% 1/4W
BD R3223M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W
ABCDE R3225 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W
ABCDE R3226 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W
BD R3243 063-10235-58 RESISTOR, FILM, 270 OHM 5% 1/4W
BD R3247 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
BD R3248 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W
BD R3249M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R3254 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W
ABCDE R3255M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R3256M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R3421 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W
ABCDE R3422M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R5101M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDE R5102M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDE R5103M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W
ABCDE R5104M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDE R5105M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDE R5106M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDE R5107M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDE R5108M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDE R5109M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W
ABCDE R5113M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W
ABCDE R5114M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W
ABCDE R5115M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W
ABCDE R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5117 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5118 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5119 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5120 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5121 063-10244-28 RESISTOR, FILM, 220K OHM 5% 1/2W
ABCDE R5122 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W
ABCDE R5123 063-10243-80 RESISTOR, FILM, 2.2K OHM 5% 1/2W
ABCDE R6001M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6002M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W
ABCDE R6003M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R6004M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W
ABCDE R6005M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6006M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W
ABCDE R6008M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R6012M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W
ABCDE R6013 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDE R6015 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDE R6016 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDE R6026 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W
ABCDE R6027 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W
ABCDE R6030 091-02053 WIRE, SOLID, BARE, 22 GA COPPER
ABCDE R6031M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R6032M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W
ABCDE R6033M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W
ABCDE R6034M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDE R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W
ABCDE R6037M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W
ABCDE R6039M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6041M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6043M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W
ABCDE R6050 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W
ABCDE R6053M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W
ABCDE R6058M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W
ABCDE R6059M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W
ABCDE R6061M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W
ABCDE R6069M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W
ABCDE R6070M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W
ABCDE R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R6080M 063-11060-18A RESISTOR, CHIP, 750K OHM 5% 1/10W
ABCDE R6090M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R6091M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W
ABCDE R6092M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W
ABCDE R6093 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDE R6094M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R6095 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDE R6096 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDE R6097 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDE R6098M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE R6099M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W
ABCDE RX2110 063-10235-10 RESISTOR, FILM, 2.7 OHM 5% 1/4W
E RX2115 063-10565-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W
BD RX2115 063-10565-06 RESISTOR, FILM, 1.8 OHM 5% 1/2W
AC RX2115 063-11110-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W
E RX2126 063-10565-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W
BD RX2126 063-10565-06 RESISTOR, FILM, 1.8 OHM 5% 1/2W
AC RX2126 063-11110-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W
ABCDE RX2278 063-10243-96 RESISTOR, FILM, 10K OHM 5% 1/2W
ABCDE RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM 1% 1/4W
ABCDE RX3009 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W
ABCDE RX3010 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W
ABCDE RX3015 063-10236-16 RESISTOR, FILM, 68K OHM 5% 1/4W
ABCDE RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W
ABCDE RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W
BD RX3202 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W
ABCDE RX3204 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W
ABCDE RX3205 063-10565 RESISTOR, FILM, 1 OHM 5% 1/2W
C RX3237 063-10442-26A RESISTOR, WIREWOUND, 1.2 OHM 5% 5W
ABD RX3237 063-10442-28A RESISTOR, WIREWOUND, 1.5 OHM 5% 5W
E RX3237 063-10442-35A RESISTOR, WIREWOUND, 3 OHM 5% 5W
ABCDE RX3242 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W
ABCD RX3261 063-10460-38A RESISTOR, WIREWOUND, 3.9 OHMS 10% 10W
E RX3261 063-10460-44A RESISTOR, WIREWOUND, 6.8 OHM 10% 10W
ABCDE RX3263 063-10244-04 RESISTOR, FILM, 22K OHM 5% 1/2W
ABCDE RX3264 063-10832-69B RESISTOR, FILM, 750 OHM 5% 1W
ABCDE RX3277 063-10565-10 RESISTOR, FILM, 2.7 OHM 5% 1/2W
ABD RX3299 063-10565-28C RESISTOR, FILM, 15 OHM 5% 1/2W
B RX3299 063-10565-38C RESISTOR, FILM, 39 OHM 5% 1/2 W
ABCDE RX3400 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M OHM 20%
1/2W
ABCDE RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68 OHM 10% 5W
ABCDE RX3403 063-10442-04A RESISTOR, WIREWOUND, 0.15 OHM 5% 5 WATT
ABCDE RX3404 063-11088-26 RESISTOR, FILM, 180K OHM 5% 1/2W
ABCDE RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W
ABCDE RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5% 1W
ABCDE RX3408 063-11156-32B RESISTOR, FILM, 22 OHM 5% 1W
ABCDE RX3409 063-11110-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W
ABCDE RX3411 063-10837B RESISTOR, FILM, 15K OHM 5% 2W
ABCDE RX3416 063-11160-56B RESISTOR, FILM, 220 OHM 5% 2W
ABCDE RX3420 063-10442-40A RESISTOR, WIREWOUND, 4.7 OHM 5% 5W
ABCDE RX3424 063-11164-08B RESISTOR, FILM, 2.2 OHM 5% 3W
