3-15
6. Tuner/IF CIRCUIT
(1) No Picture on the TV screen
No picture on the TV
screen
Does the Video signal
appear at TU701 Pin16.
YES YES
Is +33V applied to TU701
Pin14?
YES
Is +5V applied to TU701
Pin3?
NO
Does the video signal
appear at IC302 Pin32.
NO
YES
Does the Video signal
appear at IC601 Pin 4.
NO
Check the signal flow from IC601
Pin23 to JK601 Pin Video out.
YES
Check 33V line.
NO
Check 5V line.
NO
YES
Does the Clock signal
appear at TU701 Pin9?
Check the l
2
C Clock Signal
of µ-COM Pin71.
NO
YES
Does the data signal
appear at TU701 Pin10?
Replace Tuner.
Check the signal flow from
IC501 Pin26.
Check the signal from IC301 Pin26 to IC601 Pin4
Check the l
2
C Data Signal
of µ-COM Pin72.
NO
VCR ELECTRICAL TROUBLESHOOTING GUIDE
To Next Page
