1 Product overview
1.1 Product variants and identication
1.1.1 The type sign
The Zepro Z3N product family consists of the Z3N tail lift and its variants such as the Zepro Z3NW and Z3NN.
These products are available in a number of different variants with varying levels of functionality. The control
systems,cylindercongurations,availablecontrolunitsandsensorscanvarybetweenthevariants.Itis
thereforecrucialtorstidentifythevariantathandtobeabletondthecorrecttechnicalinformationforit.
Therststepintheprocessofidentifyingthevariantislocatingthetypesignandreadingtheinformation
inthetaillifttype-eld.Thelocationofthetypesignvariesbetweendifferenttailliftmodelsbutitisalways
rivetedontothesupportbeamoftheliftwiththemostcommonlocationbeingshownonthegurebelow.
There should also be a sticker showing the same information in the users manual and on the door sill on
the drivers side of the vehicle.
FortheZ3N,thefollowingnomenclatureisused.Therstthreeorfourlettersisthemodeldesignationwhere
the Z3N is the standard model, the Z3NN is a model with a narrow support frame and the Z3NW is a model
withawidesupportframe.Ifthetailliftisequippedwithanunderrunprotectiondevices,theletter"u"isadded
after the model designation. The two digit number denotes the lifting capacity of the lift, in kilograms, and the
three digit number that follows is the approximate maximum lifting height of the lift in centimeters. The lifting
heightisfollowedbythecylindercongurationandthesystemvoltage.
ZEPRO
Z3N
/
Z3NN
/
Z3NW
U 75 -100 MA 12V
Model Capacity
Lifting
height
Cylinder
conguration
System
voltage
RUPD
