ZKaccess SmartLPR Access User Manual

SmartLPR
®
Access User Manual Installation
Quercus Technologies 17
2.1. Front plate capture
2.1.1. Front plate capture
Recommended
2,5 – 3 m
Minimum distance
1,5 m
Maximum distance
5 m
The unit must always be installed at 2,5-3m from the barrier. In this type of installation, the
LPR unit captures the license plate when the vehicle arms the presence loop installed in line with
the ticket dispenser, as shown in the drawing below.
Warning:
The table above shows the recommended, minimum and maximum distance where you should
install the unit taking the barrier as reference.
3m
Barrier
Presence detection sensor
2,5m
