ZKaccess SmartLPR Access User Manual

SmartLPR
®
Access User Manual Installation
Quercus Technologies 33
5
Tighten the main body of the connector.
Tighten the cable glands at the bottom of the connector.
Once you have all the cables made, connect them to the unit and tighten firmly.
For the camera housing models, seal the connectors you did not use with the sealing cap supplied.
4.2.2. Input/Output system characteristics
The inputs have two possible states: in open circuit they indicate “0” the and in ground short
circuit they indicate “1”.
The output provides an open circuit or a ground short-circuit and leads a current of up to 200mA.
Example of an output layout with relay:
Pin
Meaning
1
IN1
2
IN2
3
OUT1
4
+ 12V
5
GND
6
Wiegand D0
7
Wiegand D1
