ZKaccess SmartLPR Access - Floor Installation

SmartLPR
®
Access User Manual Installation
Quercus Technologies 27
Fix the iron sheet on the unit using the spacer
provided.
Place the unit on the bracket, keeping the
longer side of the bracket in the front.
Install the bracket on the ceiling.
4.1.2.3. Floor installation
Remove the iron sheet from the swivel head
(you will not need it for this kind of
installation).
Place the swivel head on the vertical bracket.
