SmartLPR
®
Access User Manual Configuration
Quercus Technologies 37
4. Configuration system
Each SmartLPR
®
Access unit has an embedded configuration web from where you can configure
all the units in an installation at the same time.
To configure the units in an installation you must follow the next steps:
5.1. Login
Go to http://<IP address of the unit> (check the label of the unit), select “Normal” option and
type the password (by default "quercus2").
5.2. Lens adjustment
Once you are logged in, "Camera" window will appear. Here you can set the focus and the
zoom of the lens.
To make it easier to set the focus, adjust the brightness of the image by using the +/- controls
in "Brightness" tab.
You can adjust the lens by using the +/- zoom and focus controls.
To make sure you've properly adjusted the lens, click "Recognition" to request the license plate
recognition in the image.
