Atlas x00 Series Access Control Panels Installation Guide
Wiegand Connection
Wiegand Card Reader
Beeper
Green LED
Wiegand D1
Wiegand D0
GND
DC+(6-14V)
Figure 15
16 or 18 AWG shielded
cable recommended
