20
Atlas x00 Series Access Control Panels Installation Guide
Electrical Specications
Minimum
Typical
Maximum
Notes
WORKING POWER SUPPLY
Voltage (V) 9.6 12 14.4
Use regulated DC power
adaptor only
Current (A) 2
ELECTRONIC LOCK RELAY OUTPUT
Switching voltage (V) 12V 30V
Use regulated DC power
adaptor only
Switching Current (A) 2 3
Auxiliary relay output
Switching voltage(V) 12V 30V
Use regulated DC power
adaptor only
Switching Current (A) 1.25 1.5
SWITCH AUX. INPUT
VIH (V) TBD 30V
VIL (V) TBD
Pull- up resistance (Ω) 4.7k
The input ports are pulled
up with 4.7k resistors
WIEGAND INPUT
Voltage (V) 10.8 12 13.5
Current (mA) 500
ZK ELECTRONIC LOCK
Voltage (V) 10.8 12 13.2
Current (mA) 500
