Atlas x00 Series Access Control Panels Installation Guide

Installation Diagram

Sensor

CEILING

INDOOROUTDOOR

Atlas x00 Access Control Bundle

Electric Lock

Exit Button

Reader for “Out” DoorReader for “In” Door

Figure 23

Ethernet Communication wire

220/110 V Input
