ZKTeco Atlas 00 Series User Manual

9
Atlas x00 Series Access Control Panels Installation Guide
Cable Conduit
(Punch hole for cables)
Atlas Panel
Heat Dissipation Grill
Mounting HolesState Indicators
We recommend drilling the mounting plate screws into solid wood (i.e. stud/beam). If a stud/beam cannot be
found, then use the supplied drywall plastic mollies (anchors).
Step 1
Pass the cable through holes
Step 2
Mount the Metal Cabinet
Step 3
Fasten the Atlas Panel with four screws.
Figure 11
Figure 12
Installation of Panel & Cabinet
