Atlas Bio Series Access Control Panels Installation Guide
Copyright©2020 ZKTeco USA. All rights reserved.
Electrical
Communication TCP/IP, OSDP, WiFi, Wiegand
Power Supply 12V DC, 3A
General
Authentication Fingerprint/ Card/ PIN
CPU 32 bit 1.2GHz
RAM 256MB
Flash 1GB
Operating Temperature 32-113 °F (0-45°C)
Operating Humidity 20% to 80%
LED Indicator
Indications for Communication, Power,
Status and Prox Card
Weight Atlas-160: 9lbs (3.8kg); Atlas-260/460: 10lbs (4.2kg)
Enclosure Metal Cabinet
Mounting Mounted inside Cabinet
Dimensions (Panel Only)
Atlas-160 : 6.3in. X 5.51in. (160mm X 140mm)
Atlas-260/460 : 7.75in. X 6.73in. (197mm X 171mm)
Dimensions (Cabinet Only)
14in. X 2.5in. X 12in.
[380mm(L) X 80mm(W) X 280mm(H)]
Certied
Capacity
Max User [(1:1) or (1:N)] 5,000 (one template per nger)
Max Template [(1:1) or (1:N)] 5,000 (one template per nger)
Max Cards 5,000
Max Password 5,000
Event Database Capacity 10,000 transactions, plus unlimited archive downloads
Number of doors controlled
Four Doors (Four doors-one way and
Two doors-two ways)
Number of readers supported 4 Wiegand or 8 RS-485 or 8 OSDP
Number of Inputs 10 (4 Exit Device, 4 Door Status, 2 AUX)
Number of Outputs
5 (4- Form C relay for lock and 1- Form Crelay for AUX
output)
Interface
Baud Rate for RS485 9600-115200
Types of readers supported
125kHz and 13.56MHz Wiegand readers, OSDP (RS-
485), other readers can be congured upon request
4. Specications
4.1 PRODUCT SPECIFICATIONS
