Atlas Bio Series Access Control Panels Installation Guide

Step 1: Initial Setup

Follow the instructions under “Initial Controller Setup” and "Running the Setup Wizard", above, for each

controller. You need to select 'Secondary' under Function option in the General Settings while running the

setup wizard as shown in the image below. This will congure the controller to connect to the network.

Step 2: Adding the Controller in the Web Management Application

Secondary controllers can be automatically found and added by the Web Management Application. This is

called “Discovery”.

There are two important criteria to discover the secondary controllers.

• When using Discovery, you should connect and discover controllers one at a time. This is the only way you

can dierentiate them.

• Discovery only works if all controllers are networked on the same subnet. If you have a simple network, this

will almost always be true. In a larger corporate environment, you might need to add secondary controllers

manually. See “Special Considerations for Complex Networks” below.

To discover secondary controllers:

1. Log in to the Web Management Application (on the primary controller).

2. Go to “Cong  Hardware”.

3. Click Discover Controllers on the menu bar.

4. In a few seconds, a form will display all discovered controllers.

5. Click the link to add a controller. The create controller screen will appear.

a. Select “Conguration” (See “Initial Controller Setup”, above.)

b. Enter a “Name” and select “Custom Door Names” to name the doors.

c. Do not change other settings.

6. Click Save on the menu bar.

9. Adding Secondary Controller
