ZKTeco Atlas Bio Series User Manual

40
Atlas Bio Series Access Control Panels Installation Guide
Copyright©2020 ZKTeco USA. All rights reserved.
a. For automatic registration, click Submit Online button. You will see a progress window followed by a
success message.
b. For e-mail registration:
i. Click Oine Registration button. Read the instructions in the following window.
ii. Click Download registration le link, and save the registration data le to your computer.
iii. Create and send an e-mail message by clicking the e-mail link or entering it in your e-mail program.
Your e-mail must contain the registration data le as an attachment, with its original name. The subject
and text of the e-mail don't matter.
You will receive a registration conrmation le by a reply e-mail.
1. Open the e-mail and save the attachment to your computer.
2. Click Upload Conrmation button. (If you have already exited from registration, then return to this option
by selecting “Menu  About” and clicking the Register button.)
3. Find and open the registration conrmation le you saved.
You can see a “Registration successful” message window.
Conguration is discussed in detail in the online help topic, “Conguration: Hardware”. Topics mentioned
below are found within that section.
Go to “Cong  Hardware”. The list on the left shows all controllers. (At this point, you should see one, the
primary controller.) Each controller has an “I/O” sub-controller listed beneath it. The controller manages general
controller conguration, while the sub-controller manages detailed conguration of the readers, inputs, and
outputs.
Click the controller and review the conguration. Note under “Managed Doors” the doors are automatically
created to match the controller conguration you chose earlier. Every reader is represented as a door, whether
its function is in, out, card enrollment point, or muster point. You might need to:
• Add more readers using the “Modify” button on the menu bar. Details about this operation are in the topic,
“Modifying Controller Conguration”. The Modify options are:
o “Change to In/Out”
o “Add Muster Point”
o “Add Card Enrollment Point”
o “Remove Secondary, Muster, or Card Enrollment Point”
• Change the default connection type for readers (Wiegand, OSDP, or ZKTeco's RS-485). These settings are on
the sub-controller, and are detailed in the topic, “Hardware Properties”. The defaults vary by model and are
listed in the topic, “Models and Congurations”. Note that OSDP and ZKTeco's RS-485 cannot be combined
on the single RS-485 port.
• Change the connection properties of inputs and outputs and congure the optional functionalities of
auxiliary inputs and outputs. These settings are on the sub-controller and are detailed in the topic “Hardware
Properties”.
5. Hardware Conguration

ZKTeco Atlas Bio Series Specifications

General

Brand	ZKTeco
Model	Atlas Bio Series
Category	IP Access Controllers
Language	English
