Atlas Bio Series Access Control Panels Installation Guide

1. How do I connect two-way doors?

› Connect “Out” door readers as needed, in pair with “In” door readers according to the following table.

Model “In” Reader Pairs with "Out" Reader

1-door 1 2

2-door

1 3

2 4

4-door

1 5 (RS485 connection)

2 6 (RS485 connection)

3 7 (RS485 connection)

4 8 (RS485 connection)

› Connect door locks and sensors to the port for their “In” door.

› See “Initial Controller Setup” in the “Programming Guide” for conguration instructions and additional

options.

2. What does it mean when I get "Access Denied (Unknown Format)?"

› Your D0 and D1 wiring might be reversed.

› The type of card you swiped might not be recognized. See "Adding a User" and "User Test Access" in the

"Programming Guide."

3. How do I connect a third party reader or a stand-alone reader to an Atlas x60 panel?

› Connect the wiegand output to the WD0 and WD1 of the stand-alone readers on the panel’s reader port.

Note: The board can only supply 12V DC, 300mA power so an external power supply may be required.

4. What kind of wire is recommended for the panel?

› 16 or 18 AWG twisted shielded wire is recommended.

5. What is the default IP of the panel?

› 169.254.202.242 - This is a "link local" IP address. See "Initial Controller Setup" in the "Programming Guide"

for link local usage.

6. How long is the device under warranty?

› 2 Years from original purchase date, replacement/repair of hardware under ZK standard warranty requires an

evaluation of the failed system by a ZK Technical Support specialist, and the issuance of a Technical Support

RMA number.

12. Troubleshooting

ZKTeco Atlas Bio Series User Manual

Questions and Answers:
