ZOLL AED 3 - Battery Installation and Initial Setup; Installing the Battery Pack; Preparing Defibrillation Pads for Use

10 ZOLL AED 3 Operator’s Manual
3. Remove the battery pack from the shipping container.
4. Hold the battery pack by the side tabs with the label facing out.
Insert the battery pack into the back of the AED until it clicks into
place, lining up the notch on the end of the battery to the corre-
sponding recess in the battery well.
The defibrillator runs an automatic self test.
5. While facing the front of the defibrillator, insert the defibrillation
pads package into the back of the AED so that the label on the
package is facing you with the defibrillation pads cable on the right.
WARNING! To ensure the ZOLL AED 3 defibrillator is ready for use,
monitor its status weekly. Verify that the AED has
passed its periodic self test by confirming the green
check is displayed in the status indicator window
.
battery notch
Insert defibrillation pads package
