SECTION 7. DEFIBRILLATOR TESTS
(CONTINUED)
Perform this Action: Look for: Circle the Result
Set energy level to 30] "30J RDY" message displayed. | YES NO
Press CHARGE button
and time charge.
‘Press DISCHARGE’ "30J RDY" message YES NO
buttons. disappears.
Unit discharges. YES NO
Baseline return in <= 4 sec. YES NO
Energy delivered to defib
tester 25.5 - 34.5].
eer J YES NO
Delay time displayed on Defib
I 50 ms. analyzer < 50 ms YES NO
Set energy level to 90]
Press CHARGE button "50] RDY" message displayed.
and time charge.
YES NO
Press DISCHARGE .
buttons. "507 RDY" message
disappears.
Unit discharges. YES NO
Baseline return in <= 4 sec. YES NO
Energy delivered to defib
tester 43.5 - 57.5]. YES NO
Delay time displayed on Defib
Set energy level to 1007 analyzer < 50 ms.
Press CHARGE button | YES NO
and
time
charge.
*100]
RDY"
message
Press DISCHARGE displayed.
buttons. YES NO
"100] RDY" message
disappears.
Unit discharges. YES NO
Baseline return in <= 4 sec. YES NO
Energy delivered to defib
tester 85 - 115). YES NO
Delay time displayed on Defib
analyzer < 50 ms.
