8-7 Conversion
To
transmit 8bit-byte data in
MIDI
SysEx, any data bytes should
be
7bit-byte data.
First, strip out bit7fMSB) from source
7
bytes of da~a, and built
1
byte data attaching
MSB=O.
Then
send this byte first, and send
1st
-
7th
data without
MSB.
These
8
bytes are
combined
to
1
block.
(Fig.1)
If
stream
of
data
is
less
than
7
bytes, stream bytes
+
1
will
be a
size
of :he
block.
(Fig.2)
AAAAaaaa BBBBbbbb CCCCcccc DDDDdddd EEEEeeee
FFFFffff
SGGGgggg
4
OGFEOCBA
OAAAaaaa
OBBBbbbb OCCCcccc ODDDdddd OEEEeeee
OFFFffff
OGGSgggg
Flg.2
RAAAaaaa BBBEbbbb CCCCcccc
OOOOOCBA OAAAaaaa OBBBbbbb OCCCcccc
