ENCODER 1 PCB : PCB-0156A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
SP01435 Rotary Encoder
RE160-40E3-15A-24P-017
(same as REB161PVB15FHINA1-2-24PCE)
G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 250
*
SP02283 Harness ZH-0074-25: 2mm pitch 14pin L=250mm
1
10
ENCODER 2 PCB : PCB-0157A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
SP01435 Rotary Encoder
RE160-40E3-15A-24P-017
(same as REB161PVB15FHINA1-2-24PCE)
G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 250
SP02185 CONNECTOR 2.0T-1-3AW(Same as S3B-PHKS) G7.1ut
1
10
FOOT SW 1 PCB : PCB-0158A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
ANALOG
SP00071 OPAMP NJM2100M-TE1 G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-8, 707II etc 1 50
TRANSISTOR
SP01228 Digital Tr BCR553(Same as DTB123EK) G7.1ut, GFX-5, MRS-8, MRS-1608 5 140
SP02040 Transistor BC817-40LT1G G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 5 70
DIODE
SP00352 Diode 1SS133T-77 G7.1ut, G2, G2.1u, GFX-3, GFX-5, MRS-1608 etc 5 100
DISPLAY DEVICE
SP02049 LED KSNR-312N-30 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 5 50
SP02171 LED 3A9RYGX-C G7.1ut 5 50
POTENTIOMETER
SP02183
Trimmer potentiometer
TC-655MH501 G7.1ut 1 20
SWITCH
SP01949 TACT SW 1104RTA-2 G7.1ut, G2, G2.1u, GFX-1, GFX-3 10 100
OTHER PARTS
SP01951 CONNECTOR 2.0T-1-2A(Same as JS-1125-2) GFX-1, MRS-1608(SP01661) 1 30
SP02006 CONNECTOR 2.0T-1-3A(Same as JS1125-3) GFX-3 1 30
SP01952 CONNECTOR 2.0T-1-4A(Same as JS-1125R-4) GFX-1 1 30
SP01426 CONNECTOR 2.0T-1-10A(Same as B10B-PH-K-S) MRS-802 1 70
SP01428 CONNECTOR 2.0T-1-12A(Same as B12B-PH-K-S) G7.1ut, MRS-802 1 70
SP02187 FPC CONNECTOR 11311124-12420000 G7.1ut 1 60
*
SP02284 Harness ZH-0074-7: 2mm pitch 3pin L=320mm 1 40
*
SP02285 Harness ZH-0074-10: 2mm pitch 5pin L=340mm 1 60
*
SP02286 Harness ZH-0074-20: 2mm pitch 9pin L=80mm 1 80
*
SP02287 FPC Cable ZH-0074-26: 1mm pitch 24pin L=120mm 1 60
FOOT SW 2 PCB : PCB-0159A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
DISPLAY DEVICE
SP02049 LED KSNR-312N-30 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u
5
50
SWITCH
SP01949 TACT SW 1104RTA-2 G7.1ut, G2, G2.1u, GFX-1, GFX-3
10
100
OTHER PARTS
*
SP02288 CONNECTOR 2.0T-1-9AW
1
10
*
SP02289 Harness ZH-0074-18: 2mm pitch 8pin L=220mm
1
80
PEDAL SW-L PCB : PCB-0160A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
SWITCH
SP01949 TACT SW 1104RTA-2 G7.1ut, G2, G2.1u, GFX-1, GFX-3
10
100
OTHER PARTS
*
SP02290 Harness ZH-0074-3: 2mm pitch 2pin L=200mm
1
120
PEDAL SW-R PCB : PCB-0161A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
SWITCH
SP01949 TACT SW 1104RTA-2 G7.1ut, G2, G2.1u, GFX-1, GFX-3
10
100
OTHER PARTS
*
SP02290 Harness ZH-0074-3: 2mm pitch 2pin L=200mm
1
120
PHOTO_L PCB : PCB-0162A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
PHOTO REFLECTOR
SP00457 Photo Reflector NJL5167KB G7.1ut, G2.1u, GFX-3, GFX-5, GFX-8, 707II
1
100
OTHER PARTS
*
SP02291 Harness ZH-0074-6: 2mm pitch 3pin L=150mm
1
30
PHOTO-R PCB : PCB-0163A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
PHOTO REFLECTOR
SP00457 Photo Reflector NJL5167KB G7.1ut, G2.1u, GFX-3, GFX-5, GFX-8, 707II
1
100
OTHER PARTS
*
SP02291 Harness ZH-0074-6: 2mm pitch 3pin L=150mm
1
30
PHOTO_Z PCB : PCB-0164A
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
PHOTO REFLECTOR
*
SP02292 Photo Reflector GP2S40J
1
190
OTHER PARTS
*
SP02293 Harness ZH-0074-9: 2mm pitch 4pin L=250mm
1
40
- 52 -
