ANALOG PCB : PCB-0165
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
USB CODEC
SP02088 USB CODEC PCM2904DBR G7.1ut, G2.1u, B2.1u, A2.1u
1
600
ANALOG
SP00078 OPAMP NJM4556M-TE1 G7.1ut, G2, G2.1u, GFX-8, MRS-1608 etc
1
50
SP00070 OPAMP NJM4558M-TE1 (Same as BA4558F) G7.1ut, G2, G2.1u, GFX-8, MRS-1608 etc
1
40
SP00071 OPAMP NJM2100M-TE1 G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-1608 etc
1
50
POWER SUPPLY
SP02090 Voltage Regulator XC6213B332MR
G2.1u, B2.1u, A2.1u
1
40
SP02196 Voltage Regulator TA7812S (Same as uPC7812AHF)
G7.1ut
1
70
SP02197 Voltage Regulator TA79012S (Same as uPC7912AHF)
G7.1ut
1
130
SP02198 Voltage Regulator S-8520F50MC-BOJ-T2
G7.1ut
1
60
TRANSISTOR
SP01199 Transistor 2SC3326 G7.1ut, MRS-802, MRS-1266, MRS-1608
5
50
SP02199 Transistor 2SA1213
5
80
SP02039 Transistor BC807-40LT1G G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u
5
70
SP02200 Digital Tr DTA124EKA G7.1ut
5
50
SP02201 Digital Tr MUN5112DW1T1G (Same as UMB1N and XP04112)
G7.1ut
5
130
DIODE
SP00704 Chip Shottky Diode RB160L-40TE25 G7.1ut, G2, G2.1u, MRT-3, MRS-4, PS-02, PS-04
5
150
SP00123 Diode 1N4003 G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-8 etc
5
100
SP00352 Diode 1SS133T-77 G7.1ut, G2, G2.1u, GFX-3, GFX-5, MRS-1608 etc
5
100
OSCILLATOR
SP02092 Crystal Oscillator HC49S3 12MHz G7.1ut, G2.1u, B2.1u, A2.1u
1
70
INDUCTOR
SP02202 Inductor LQH55DN220M03(22uH) (Same as CDRH5D28R-220) G7.1ut
1
110
SP01762 Chip Inductor BLM18AG102SN1 G7.1ut, G2, G2.1u, MRS-8
10
200
POTENTIOMETER
SP02203
Trimmer potentiometer
TC-655MH103 G7.1ut
1
20
JACK, SOCKET
SP01499 Stereo Mini Jack SJ-3507-5P(Same as ST-214-C-02) G7.1ut, GFX-5
1
70
SP00590 Stereo Phone Jack SJ6336 (Same as HTJ-064-12D) G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-5, GFX-8
1
100
SP00589 Phone Jack SJ6335 (Same as HTJ-064-12I) G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-5, GFX-8
1
100
OTHER PARTS
SP00910 Slide SW SK22H09-G9 (Same as HSW2022-010020) G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-8 etc
1
30
SP02204 Volume F-095V5G A10K L15FC*7 (M)
G7.1ut
1
140
SP02093 USB Connector 57112201-2110000 G7.1ut, G2.1u, B2.1u, A2.1u
1
40
SP02162 Connector 3.96T-3-3A (Same as B3P-VH)
G7.1ut
1
20
SP02006 Connector 2.0T-1-3A (Same as JS-1125-3 and B3B-PHKS) G7.1ut, G2, G2.1u, GFX-3
1
30
SP01425 Connector 2.0T-1-6A (Same as B6B-PHKS) G7.1ut, MRS-802
1
50
SP02163 Connector 2.0T-1-7A (Same as B7B-PHKS)
G7.1ut
1
70
SP02164 Connector 2.0T-1-8A (Same as B8B-PHKS)
G7.1ut
1
10
SP01426 Connector 2.0T-1-10A (Same as B10B-PHKS) MRS-802
1
70
*
SP02294 Harness ZH-0074-2: 3.96mm pitch 2pin L=380mm
1
70
*
SP02295 Harness ZH-0074-14: 2mm pitch 6pin L=220mm
1
60
*
SP02296 Harness ZH-0074-15: 2mm pitch 7pin L=200mm
1
70
*
SP02297 Harness ZH-0074-27: 2mm pitch 10pin L=185mm
1
80
TUBE PCB : PCB-0166
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
TUBE
SP02209 TUBE 12AX7 G7.1ut
1
1180
OTHER PARTS
SP02210 TUBE SOCKET GZC9-1B G7.1ut
1
120
SP02164 Connector 2.0T-1-8A (Same as B8B-PHKS) G7.1ut
1
10
*
SP02298 Harness ZH-0074-19: 2mm pitch 8pin L=60mm (Same as ZH-0074-16)
1
60
ACC TUBE PCB : PCB-0167
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
TUBE
SP02209 TUBE 12AX7 G7.1ut
1
1180
OTHER PARTS
SP02210 TUBE SOCKET GZC9-1B G7.1ut
1
120
SP02164 Connector 2.0T-1-8A G7.1ut
1
10
*
SP02298 Harness ZH-0074-16: 2mm pitch 8pin L=60mm (Same as ZH-0074-19)
1
60
PCB
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen)
PCB ASSEMBLY
*
SP40165 G9.2tt MAIN PCB Assy
FR-4 4layer 113x95mm
(PCB-0151 with Harness)
1 3000
*
SP40166 G9.2tt PANEL PCB Assy
FR-1 One side pattern 149x106.5mm
(PCB-0154A, PCB-155A with Harness)
1 2000
*
SP40167 G9.2tt ENCODER PCB Assy
FR-1 One side pattern 130x34mm
(PCB-0156A, PCB-0157A with Harness)
1 480
*
SP40168 G9.2tt FOOT SW PCB Assy
FR-1 One side pattern 379x44mm
(PCB-0158A, PCB-0159A, PCB-164A with Harness)
1 940
*
SP40169 G9.2tt PEDAL SW PCB Assy
FR-1 One side pattern 152x30mm
(PCB-0160A, PCB-161A, PCB-162A, PCB-0163A with
1 250
*
SP40170 G9.2tt ANALOG PCB Assy
FR-4 2layer 284x100mm
(PCB-0165, PCB-0166, PCB-0167 with Harness)
1 2000
