Zoom g9.2tt - Page 54

MECHANICAL PARTS LIST
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
TOP COVER
*
SP02299 G9.2tt TOP CASE Z2A-0108
1 1770
LOWER PANEL
*
SP02300 G9.2tt BOTTOM PLATE Z2A-0109
1 690
SIDE COVER
SP02214 G7.1ut SIDE COVER L Z2B-0203
G7.1ut 1 110
SP02215 G7.1ut SIDE COVER R Z2B-0204
G7.1ut 1 110
BUTTON, KNOB
SP02216 G7.1ut SWITCH BUTTON A Z2B-0195
G7.1ut 1 30
SP02059 VR KNOB 1 Z2B-0160
G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 30
SP02060 VR KNOB 2 Z2B-0161
G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 30
SP02217 G7.1ut VR KNOB 2 Z2B-0200
G7.1ut 1 20
SP02218 G7.1ut ENCODER KNOB 2 Z2B-0201
G7.1ut 1 10
SP02219 G7.1ut VR KNOB 3 Z2B-0202
G7.1ut 1 20
SP02220
G7.1ut EX PEDAL BUTTON Z2B-0208 G7.1ut 1 10
RUBBER, SPRING
SP02025 GFX3 CUSHION RUBBER Z2D-0042-A4
GFX-3
1 10
SP01964 GFX-1 FOOT RUBBER B
Z2D-0040-A4 GFX-1 1 10
SP02247 G7.1ut EX PEDAL RUBBER Z2D-0058
G7.1ut 1 60
SP02121
CUSHION EX-PEDAL Z2D-0062
G7.1ut 1 10
*
SP02301 EX-PEDAL SPRING Z2A-0123
1 10
SHEET, COLOR FILTER
SP02248 G7.1ut DISPLAY SHEET Z2E-0214
G7.1ut 1 20
SP01535 G7.1ut REFLECT SEAL
Z2E-5032-A4 G7.1ut, G2.1u, GFX-3, GFX-5 1 40
SP02249 G7.1ut EX BUTTON PAD Z2D-0059
G7.1ut 1 10
*
SP02302 G9.2tt rubber pad
Z2D-0061 1 10
SCREW, WASHER, NUT
SP00291 SCREW M3.0x8L P-TIGHT
G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u, MRT-3
10
20
SP01285 SCREW M3.0x5L S_TIGHT, SWCH(Fe), Black Chromate
MRS-1266
10
320
SP01804 TAPE SCREWS M3.0x8L B-TIGHT
RT-223
10 100
SP02027 SCREW M3.0x8L S_TIGHT, SWCH(Fe), Black Chromate
G7.1ut, GFX-3
10
10
SP02245 G7.1ut PCB SPACER HP-13.5
G7.1ut 10 10
SP02251 SPRING WASHER d5.2xd3.2xt1.0
G7.1ut
10 10
SP02252 G7.1ut SCREW Z2B-0032, M4.0X5.0,BLACK, no head
G7.1ut 10 90
SP02253 G7.1ut SCREW M4.0x8L, SWCH(Fe),Black Chromate HEXAGON SOCKET HEAD
G7.1ut
10
10
SP02258 NUT M3.0,black
G7.1ut
10 10
*
SP02303 SPACER d=10.0 t=0.1
10 50
*
SP02305 PLAIN WASHER d6.6xd3.2xt1.0
10 10
*
SP02306 SCREW M2.6x4L, P-TIGHT
10 10
*
SP02307 SCREW M2.6x5L, P-TIGHT
10
10
*
SP02308 SCREW M3.0x4L, S-TIGHT FLAT HEAD
10 10
*
SP02309 SCREW M3.0x6L, COMMON HEAD,black
10
10
*
SP02310 SCREW M3.0X12L
10 20
*
SP02311 SCREW M3.0X14L, P-TIGHT
10
20
*
SP02312 SCREW M3.0x22L, S-TIGHT
10 20
*
SP02313 SCREW M3.0X9L
10 20
*
SP02314 G9.2tt ZM_SP_01
Z2B-0223 10 80
*
SP02315 G9.2tt ZM_SP_02
Z2B-0224 10 80
OTHER MOULDING PARTS
SP02062 FOOT SW UNIT Z2A-0089
G7,1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 130
SP02221 G7.1ut EX PEDAL SPACER Z2B-0212
G7.1ut 1 10
SP02222 G7.1ut FOOT SW DRESS PLATE Z2B-0206
G7.1ut 1 30
SP02223 G7.1ut FOOT SW BRACKET Z2A-0093
G7.1ut 1 60
SP02224 G7.1ut DISPLAY COVER Z2B-0205
G7.1ut 1 70
SP02226 G7.1ut CORD HOOK Z2B-0209
G7.1ut 1 10
SP02227 G7.1ut AC BRACKET Z2A-0096
G7.1ut 1 10
SP02228 G7.1ut EX PEDAL BRACKET Z2B-0210
G7.1ut 1 10
SP02229 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100
G7.1ut 1 10
SP02230 G7.1ut EX PEDAL GUIDE Z2A-0095
G7.1ut 1 30
SP02231 G7.1ut EX PEDAL BASE Z2B-0211
G7.1ut 1 460
SP02232 G7.1ut EX PEDAL POLE Z2A-0101
G7.1ut 1 40
SP02233 G7.1ut REFLECT BRACKET Z2B-0207
G7.1ut 1 10
SP02237
G7.1ut SIDE BRACKET_RIGHT Z2A-0099 G7.1ut 1 150
SP02238 G7.1ut SHIELD CASE Z2A-0105
G7.1ut 1 20
SP02239 G7.1ut LED SPACER SUPPORT 1 LED-16
G7.1ut 1 10
SP02240 G7.1ut LED SPACER SUPPORT 2 LED3x16
G7.1ut 1 10
SP02241 G7.1ut THREAD SPACER HP_12
G7.1ut 1 10
SP02243 G7.1ut SPACER SUPPORT 2 MADM-2
G7.1ut 1 10
*
SP02316 G9.2tt ROUND SPACER
3.5-12 1 10
*
SP02317 G9.2tt ROUD SPACER 3-2
1 10
*
SP02318
G9.2tt MACHINE BAR Z2A-0110 1 290
*
SP02319
G9.2tt TUBE BRACKET A Z2A-0111 1 50
*
SP02320
G9.2tt TUBE SP BRACKET Z2A-0112 1 50
*
SP02321 G9.2tt HEATSINK
Z2A-0113 1 100
*
SP02322 G9.2tt FOOT SW BRACKET 2 Z2A-0116
1 80
*
SP02323 G9.2tt TUBE COVER A
Z2A-0119 1 50
*
SP02324 G9.2tt TUBE COVER B
Z2A-0120 1 50
*
SP02325 G9.2tt Shield plate
Z2A-0121 1 130
*
SP02326 G9.2tt copper support
Z2A-0122 1 20
*
SP02327
G9.2tt SIDE BRACKET_LEFT Z2A-0124
1
150
- 54 -
