Z-PEDAL MECHANICAL PARTS LIST
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
RUBBER, SPRING
SP02025 GFX3 CUSHION RUBBER Z2D-0042-A4 G7.1ut, GFX-3
1 10
*
SP02328 Z-PEDAL RUBBER Z2D-0060 1
40
*
SP02347 CUSHION Z-PEDAL 1 Z2D-0063 1
10
*
SP02348 CUSHION Z-PEDAL 2 Z2D-0064 1
10
SCREW, WASHER, NUT
SP00291 TAPE SCREWS M3.0x8L P_TIGHT, SWCH(Fe), Black Chromate G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u, MRT-3 10
20
SP02027 TAPE SCREWS M3.0x8L S_TIGHT, SWCH(Fe), Black Chromate G7.1ut, GFX-3 10
10
*
SP02308 SCREW M3.0x4L, S-TIGHT FLAT HEAD 10
10
SP02252 G7.1ut SCREW Z2B-0032, D5.0, M4.0X5.0,BLACK, no head, G7.1ut 10
90
SP02253 G7.1ut SCREW M4.0x8L, SWCH(Fe),Black Chromate HEXAGON SOCKET HEAD G7.1ut 10
10
*
SP02329 E-RING 5mm,white nickel plated 10
20
*
SP02330 PLAIN WASHER d=14.0xd=8.5xt=0.5 10
120
OTHER MOULDING PARTS
SP02221
G7.1ut EX PEDAL SPACER Z2B-0212
G7.1ut
1 10
SP02228 G7.1ut EX PEDAL BRACKET Z2B-0210 G7.1ut
1 10
SP02229 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 G7.1ut
1 10
SP02230 G7.1ut EX PEDAL GUIDE Z2A-0095 G7.1ut 1
30
SP02232 G7.1ut EX PEDAL POLE Z2A-0101 G7.1ut 1
40
*
SP02331 Z-PEDAL POLE Z2A-0114 1
70
*
SP02332 Z-PEDAL PIN Z2A-0115 1
30
*
SP02333 Z-PEDAL BASE 1 Z2B-0214 1
320
*
SP02334 Z-PEDAL BASE 2 Z2B-0215 1
470
*
SP02335 Z-PEDAL LOCK CAM 1 Z2B-0216 1
60
*
SP02336 Z-PEDAL LOCK CAM 2 Z2B-0217 1
60
*
SP02337 Z-PEDAL REFLECT BRACKET Z2B-0219 1
10
*
SP02338 Z-PEDAL GUIDE PLATE 1 Z2B-0220 1
10
*
SP02339 Z-PEDAL GUIDE PLATE 2 Z2B-0221 1
10
*
SP02340 Z-PEDAL BLAKE Z2B-0222 1
10
PACKING PARTS LIST
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
CARTON BOX
*
KS00169 G9.2tt MASTER Carton Box Z2F-0045
1
400
*
KS00170 G9.2tt Gift Box Z2F-0044
1
460
SPACER
KS00166
G9.2tt Corrugated Spacer-1
package_sub_card_R (Same as G7.1ut Corrugated Spacer-3) G7.1ut
1
10
KS00167
G9.2tt Corrugated Spacer-2
package_adaptor_card (Same as G7.1ut Corrugated Spacer-4) G7.1ut
1
20
KS00164
G9.2tt Corrugated Spacer-3
3 package_side_card (Same as G7.1ut Corrugated Spacer-1) G7.1ut
1
10
*
KS00173
G9.2tt Corrugated Spacer-6
package_top_card
1
30
CARD, SHEET
SP02261 DAW Starting Manual Japanese G7.1ut, G2.1u, B2.1u, A2.1u
1
20
SP02262 DAW Starting Manual English G7.1ut, G2.1u, B2.1u, A2.1u
1
20
*
SP02341 G9.2tt Patch List Sheet Z2I-0659 Japanese
1
20
*
SP02342 G9.2tt Patch List Sheet Z2I-0660 English
1
20
*
SP02343 G9.2tt Modeling Description Z2I-0664 Japanese
1
20
*
SP02344 G9.2tt Modeling Description Z2I-0665 English
1
20
*
SP02345 Pedal adjustment supplemental sheet
1
20
- 55 -
