Zoom GFX-707 User Manual

This module contains a 4-band equalizer for making tone adjustments. The equalizer has only one effect type, but because there are
many parameters, it is divided into two pages titled EQ P1 and EQ P2. (Use the MODULE / keys to switch between pages.) This
module also comprises the ZNR settings.
The original noise reduction developed by Zoom cuts noise
during performance pauses without impairing the sound quality.
Adjusts ZNR sensitivity. The recommended approach is to set the
value as high as possible without producing an unnatural cut of
the instrument sound. When set to "oF", ZNR is disabled.
ZNR operates independently of the EQ module. The ZNR
setting will be active also if the EQ module is off, and the EQ
module and ZNR can also be used together.
This page of the 4-band equalizer allows adjustment from the
extreme high range to the midrange.
Controls boost/cut in ultra high range (center frequency 8 kHz).
Controls boost/cut in high range (center frequency 3.125 kHz).
Controls boost/cut in midrange (center frequency 800 Hz).
This page of the 4-band equalizer allows adjustment in the low range.
1 selects the ultra low range (center frequency 63 Hz) and 2 the
low range (center frequency 125 Hz).
Controls boost/cut in the range selected with LOW F.
Adjusts volume level after passing EQ module.
(EQ page 2)
EQ P2
(EQ page 1)
EQ P1
(Zoom Noise Reduction)
ZNR
ZOOM GFX-707
This effect makes an electric guitar sound like an acoustic guitar.
Adjusts characteristic sound of acoustic guitar strings.
Adjusts body resonance.
Adjusts volume level after passing COMP•DIST module.
This is a fast-attack compressor.
* TYPE 2 and 3 parameters are identical.
Selects sound character.
FL(Flat): Clean sound with flat characteristics
Ft(Fat Clean): Clean sound with prominent midrange
bt(Bright): Clean sound with vivid mid/high range
Adjusts depth of compressor effect. "oF" means that effect is
disabled.
Adjusts volume level after passing COMP•DIST module.
This is a slow-attack compressor.
Combination of compressor and crunch.
* TYPE 4 - 7 parameters are identical.
Adjusts distortion depth.
Adjusts depth of compressor effect.
Adjusts volume level after passing COMP•DIST module.
This is a combination of compressor and overdrive.
This is a combination of compressor and distortion.
This is a combination of compressor and fuzz.
This effect produces a dry overdrive sound. * TYPE 8 - 16
parameters are identical.
1 – 30
Adjusts distortion intensity.
0 – 10
Adjusts tonal quality.
1 – 8
Adjusts volume level after passing COMP•DIST module.
This effect produces an overdrive sound with a pronounced cabinet character.
This effect produces a dry distortion sound.
This effect produces a strong distortion sound.
Produces fuzz sound reminiscent of the sixties.
Produces high-gain, aggressive fuzz sound.
Produces sound with a distinctive midrange character.
Produces high-gain sound with boosted low and high end.
Simulates the sound of a large amplifier.
PWR DRV (Power Drive)
TYPE 16
METAL
TYPE 15
LEAD
TYPE 14
WILDFZ (Wild Fuzz)
TYPE 13
FUZZ
TYPE 12
DIST2 (Distortion 2)
TYPE 11
DIST2 (Distortion 2)
TYPE 10
OD2 (Overdrive 2)
TYPE 9
LEVELParameter 3
TONEParameter 2
GAINParameter 1
OD1 (Overdrive 1)
TYPE 8
CMP+FZ (Compressor + Fuzz)
TYPE 7
CMP+DS (Compressor + Distortion)
TYPE 6
CMP+OD (Compressor + Overdrive)
TYPE 5
CMP+CR (Compressor + Crunch)
TYPE 4
CMP SL (Compressor/slow)
TYPE 3
CMP FS (Compressor/fast)
TYPE 2
ACOSIM (Acoustic simulator)
TYPE 1
TOP 1 – 10Parameter 1
COLOR FL, Ft, btParameter 1
COMP oF, 1 – 10Parameter 2
LEVEL 1 – 8Parameter 3
LEVEL 1 – 8Parameter 3
PRESEN -12 – 12Parameter 1
GAIN 1 – 30Parameter 1
COMP oF, 1 – 10Parameter 2
BODY 1 – 10Parameter 2
LEVEL 1 – 8Parameter 3
17
Effect Types and Parameters
In this section, all effect types and parameters of the GFX-707 are explained. Parameters that are the same for several
effects are explained in detail only the first time they appear.
The [ ] mark indicates that this parameter can be assigned to the expression pedal ( p. 22).
The - marks indicate parameters that can be controlled with the parameter knobs 1 - 3 in play mode.
Effect Types and Parameters
COMP•DIST (compressor/distortion) module
In addition to various distortion effects such as overdrive and fuzz, this module contains a clean compressor and acoustic guitar
simulator.
ZNR/EQ (Zoom Noise Reduction/Equalizer) module
NOTE
ZNR OF, 1 – 7Parameter 1
HIGH -12 – 12Parameter 2
MIDDLE -12 – 12Parameter 3
LOW F 1, 2Parameter 1
LOW G -12 – 12Parameter 2
LEVEL 1 – 8Parameter 3

Zoom GFX-707 Specifications

Effect Specifications

effect programs	48 types
effect modules	4 modules + amp simulator + ZNR
sampler function maximum recording time	6 seconds

Memory and Processing

patch memory user	6 banks x 5 = 30
patch memory preset	6 banks x 5 = 30
sampling frequency	31.25 kHz

Conversion and DSP

a/d conversion	20-bit, 64-times oversampling
d/a conversion	20-bit, 128-times oversampling
dsp	ZOOM original ZFx-2

Input and Output

guitar input nominal input level	-20 dBm
guitar input input impedance	470 kilohms
maximum output level	+3 dBm

Display and Power

display	6-position alphanumeric LED display
power supply	9 V DC, center minus, 300 mA
continuous operation	approx. 14 hours with alkaline batteries

Weight and Dimensions

external dimensions	235 mm (W) x 189 mm (D) x 54 mm (H)
weight	740 g
batteries	IEC R6 (size AA) x 4
